RDA5856TE

Bluetooth audio SoC, BR/EDR+BLE, A2DP/HFP/AVRCP profiles, stereo codec 95dB DAC SNR, FM receiver with RDS, integrated MC

4507

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

RDA5856TE

Package：

QFN-32/QFN-40 (4x4mm / 5x5mm)

Brand：
Product Categories：

Quality Commitment

Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

SI8261BCC-C-IS

RM5532AL

RA80H1415M1

R5F109BCK

R2A20178NP

QMC5883L

PS2805C-1-F3-A

PIC32MZ1024ECG100-I

Description

Product Overview

The RDA5856TE is a high-performance electronic component from RDA Micro, featuring a QFN-32/QFN-40 (4x4mm / 5x5mm) package. It is designed for a wide range of applications including industrial, consumer, and communication systems, delivering reliable performance and excellent value.

Key Specifications

Parameter Bluetooth audio SoC
Parameter BR/EDR+BLE
Parameter A2DP/HFP/AVRCP profiles
Parameter stereo codec 95dB DAC SNR
Parameter FM receiver with RDS
Parameter integrated MCU+ROM+RAM
Parameter headphone amp
Parameter ~25mA A2DP current
Parameter 3.0-4.2V
Parameter QFN
Package QFN-32/QFN-40 (4x4mm / 5x5mm)

Features

  • Fully integrated Bluetooth audio SoC (radio + codec + MCU)
  • Bluetooth BR/EDR + BLE dual mode
  • Supports A2DP 1.3, AVRCP 1.6, HFP 1.7, HSP, SPP
  • High-quality stereo audio codec (16-24bit, up to 48kHz)
  • High SNR: >95 dB DAC, >85 dB ADC
  • Integrated stereo headphone amplifier (32mW/ch)
  • FM radio receiver with RDS/RBDS (76-108MHz)
  • Built-in 16/32-bit RISC application processor
  • On-chip ROM and SRAM, fully programmable
  • I2S digital audio interface (master/slave)
  • Stereo ADC for microphone/line input
  • Multiple GPIOs for buttons and LED control
  • UART and I2C master/slave interfaces
  • Integrated Li-ion battery charger (some variants)
  • Low power: ~25mA A2DP playback
  • Deep sleep mode <100uA
  • Single supply 3.0-4.2V (Li-ion battery)
  • Internal LDOs for power management
  • Compact QFN package
  • Firmware upgradeable via UART

Applications

  • Bluetooth portable speakers
  • Bluetooth headphones and earphones
  • Bluetooth car kits and hands-free devices
  • Wireless audio adapters and receivers
  • FM radio with Bluetooth output
  • Smart audio devices and voice assistants
  • Home audio and mini soundbars
  • Toys and wearable audio devices

The RDA5856TE is a high-performance electronic component manufactured by RDA Micro. Packaged in a QFN-32/QFN-40 (4x4mm / 5x5mm), this device offers an excellent balance of performance, power efficiency, and cost-effectiveness for demanding electronic applications.

Key characteristics include: Fully integrated Bluetooth audio SoC (radio + codec + MCU); Bluetooth BR/EDR + BLE dual mode; Supports A2DP 1.3, AVRCP 1.6, HFP 1.7, HSP, SPP; High-quality stereo audio codec (16-24bit, up to 48kHz); High SNR: >95 dB DAC, >85 dB ADC. It is well-suited for use in Bluetooth portable speakers, Bluetooth headphones and earphones, Bluetooth car kits and hands-free devices.

With its robust design and reliable performance across the specified operating range, the RDA5856TE is an excellent choice for both new designs and drop-in replacement applications.

The RDA5856TE operates based on semiconductor principles optimized for its specific function. It receives input signals or power, processes them according to its internal circuitry, and delivers the expected output with high accuracy and reliability.

Internal blocks may include signal conditioning, power regulation, and protection circuits to ensure stable operation across the full range of specified operating conditions. The device is designed to minimize power consumption while maximizing performance efficiency.

For detailed operational characteristics, timing diagrams, and electrical specifications, please refer to the official datasheet.

Pin Group Function
Power Pins VDD/VCC (positive supply), VSS/GND (ground)
Signal I/O Pins Input/output signals for device operation
Control Pins Configuration and control interface pins

Note: Exact pin assignment varies by package variant (QFN-32/QFN-40 (4x4mm / 5x5mm)). Refer to the official datasheet for complete pin descriptions and package dimensions.

  • Bluetooth portable speakers
  • Bluetooth headphones and earphones
  • Bluetooth car kits and hands-free devices
  • Wireless audio adapters and receivers
  • FM radio with Bluetooth output
  • Smart audio devices and voice assistants
  • Home audio and mini soundbars
  • Toys and wearable audio devices
Part Number Description
RDA5850TE entry-level, fewer features
JL AC6925 cost-effective alternative
Qualcomm QCC3034 premium, aptX, ANC
Realtek RTL8763BFR BT5.0, TWS
Actions ATS2819 BT5.0, low cost
