IR2085STRPBF

Infineon IR2085STRPBF self-oscillating half-bridge driver, 100V, 1A, 500kHz, SOIC-8

10250

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

IR2085STRPBF

Package：

SOIC-8

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

OC5A2B00

NCV887103D1R2G

NAE12S17-A

MIC4428YM

MIC2951-03BN

LTM4673Y

LTC3780IG

LTC3112EFE

Description

Product Overview

The IR2085STRPBF is a self-oscillating half-bridge driver IC from Infineon Technologies. With integrated 50% duty cycle oscillator and high/low side gate drivers in a single SO-8 package, this device simplifies half-bridge DC-bus converter designs for 36V to 75V distributed power systems.

Key Specifications

Manufacturer Infineon Technologies
Device Type Self-Oscillating Half-Bridge Driver
V_OFFSET ≤ 100 V
Output Current 1.0 A source / 1.0 A sink (typical)
Oscillator Frequency Up to 500 kHz (per channel)
Dead Time 50 ns to 200 ns (adjustable)
HO/LO Pulse Matching ±25 ns
Supply Voltage 10V to 15V (recommended)
UVLO Threshold 7.5 V
Package SOIC-8
Operating Temperature -40°C to +125°C

Features

  • Integrated 50% duty cycle oscillator + half-bridge driver
  • Single SOIC-8 package reduces board space
  • Programmable frequency up to 500kHz per channel
  • Adjustable dead time: 50ns to 200ns
  • Floating channel for bootstrap operation up to 100V
  • Overcurrent protection with auto-restart
  • Undervoltage lockout and soft-start
  • ±25ns pulse matching between high/low sides
  • RoHS compliant, lead-free

Applications

  • 48V distributed power systems
  • Half-bridge DC-DC converters
  • Push-pull converters
  • Telecom and datacom power supplies
  • Server point-of-load converters
  • Isolated power modules
  • Industrial auxiliary power supplies

The IR2085STRPBF is a self-oscillating half-bridge gate driver IC from Infineon Technologies, designed specifically for 36V to 75V half-bridge DC-bus converter applications. This device integrates a fixed 50% duty cycle oscillator with a high-side and low-side gate driver in a compact SOIC-8 package, drastically reducing component count and board space compared to discrete solutions. The switching frequency is user-programmable via an external RT/CT network, with each channel operating at the oscillator frequency. Dead time is adjustable from 50ns to 200ns through the timing capacitor selection. The IR2085S also features integrated overcurrent protection, undervoltage lockout, and soft-start functionality for reliable operation.

The IR2085STRPBF integrates a 50% duty cycle oscillator with a high-voltage half-bridge driver. The oscillator uses an external timing resistor (RT) and timing capacitor (CT) to set the switching frequency, where fOSC = 1/(2×RT×CT). The oscillator alternately drives the high-side and low-side outputs with 50% duty cycle. The CT value also determines the dead time between high-side and low-side transitions. Internal soft-start circuitry gradually increases pulse width during power-up and after each overcurrent event. The high-side driver uses bootstrap technique to drive the high-side MOSFET, with the floating channel rated for up to 100V offset voltage. Overcurrent protection is implemented via the CS pin, which monitors the current sense signal.

Pin Number Pin Name Function
1 VCC Low-Side Supply Voltage
2 HO High-Side Gate Drive Output
3 VB Floating High-Side Supply (Bootstrap)
4 RT Oscillator Timing Resistor
5 CT Oscillator Timing Capacitor
6 CS Current Sense Input
7 COM Ground / Common
8 LO Low-Side Gate Drive Output
  • 48V to low-voltage DC-DC converters
  • Distributed power systems
  • Half-bridge isolated converters
  • Push-pull converter topologies
  • Telecom and datacom power supplies
  • Server power systems
  • Industrial auxiliary power modules
Model Manufacturer Description
IR2085SPBF Infineon DIP-8 through-hole version
UCC27201 TI Alternative 100V half-bridge driver
FAN7390 ON Semiconductor Alternative half-bridge gate driver
