IR2111STRPBF

Infineon IR2111STRPBF half-bridge gate driver, 500V, 250mA/500mA, SOIC-8

11340

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

IR2111STRPBF

Package：

SOIC-8

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

OC5A2B00

NCV887103D1R2G

NAE12S17-A

MIC4428YM

MIC2951-03BN

LTM4673Y

LTC3780IG

LTC3112EFE

Description

Product Overview

The IR2111STRPBF is a high-voltage half-bridge gate driver IC from Infineon Technologies. This 500V driver integrates high-side and low-side channels with independent logic inputs in a compact SOIC-8 package, designed for driving N-channel power MOSFETs and IGBTs in half-bridge configurations.

Key Specifications

Manufacturer Infineon Technologies
Device Type Half-Bridge Gate Driver
V_OFFSET 500 V (max)
Output Current (Source/Sink) 250 mA / 500 mA (typ)
Supply Voltage Range 10 V to 20 V
UVLO Threshold 8.6 V (on) / 8.2 V (off)
Dead Time Internal (typ 500ns)
Propagation Delay 680 ns (on) / 260 ns (off)
Input Logic CMOS / LSTTL compatible
Package SOIC-8
Operating Temperature -40°C to +125°C

Features

  • Floating channel for bootstrap operation up to 500V
  • dV/dt immune, negative transient tolerant
  • Gate drive supply range: 10V to 20V
  • Undervoltage lockout
  • Internal dead time prevents shoot-through
  • CMOS Schmitt-triggered inputs
  • Single input controls both channels
  • Outputs are complementary
  • RoHS compliant, SOIC-8 package

Applications

  • Half-bridge DC-DC converters
  • Motor drives
  • Switch-mode power supplies
  • Electronic ballasts
  • Class D audio amplifiers
  • UPS systems
  • LED lighting drivers
  • Industrial power systems

The IR2111STRPBF is a high-voltage, high-speed half-bridge power MOSFET and IGBT driver from Infineon Technologies. This device integrates both high-side and low-side driver channels in a single SOIC-8 package, with complementary output operation controlled by a single logic input. The floating high-side channel, designed for bootstrap operation, is fully operational up to 500V offset voltage. Internal dead time of approximately 500ns ensures reliable operation by preventing cross-conduction (shoot-through) in the power stage. Built on Infineon’s proven HVIC and latch-immune CMOS technology, the IR2111S offers robust performance and excellent noise immunity for a wide range of half-bridge power conversion applications.

The IR2111STRPBF operates as a complementary-output half-bridge gate driver. A single input (HIN/LIN combined) controls both the high-side and low-side outputs. When the input is high, the low-side output (LO) is high and the high-side output (HO) is low. When the input goes low, after the internal dead time delay, the low side turns off and the high side turns on. This complementary switching with built-in dead time simplifies half-bridge design by eliminating the need for external dead time generation circuitry. The high-side driver operates from a floating bootstrap supply (VB-VS), while the low-side driver operates from the fixed VCC supply. UVLO circuitry ensures both outputs remain low if supply voltage is insufficient.

Pin Number Pin Name Function
1 LO Low-Side Gate Drive Output
2 VCC Low-Side Power Supply (10-20V)
3 IN Logic Input (Controls Both Channels)
4 SD Shutdown Input (Active High)
5 COM Common / Ground
6 VS High-Side Floating Return
7 HO High-Side Gate Drive Output
8 VB High-Side Floating Supply (Bootstrap)
  • Half-bridge DC-DC converter topologies
  • Brushless DC motor drivers
  • Switch-mode power supplies
  • Fluorescent lamp electronic ballasts
  • Class D audio amplifier output stages
  • Uninterruptible power supplies
  • LED driver circuits
  • Industrial power conversion systems
Model Manufacturer Description
IR2101STRPBF Infineon Dual input, lower current version
IR2113STRPBF Infineon 600V, 2.5A with SD, SOIC-16W
IR2111PBF Infineon DIP-8 through-hole version
