IR2113STRPBF

Infineon IR2113STRPBF EiceDRIVER 600V gate driver, 2.5A/2.5A, with shutdown, SOIC-16W

1084

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

IR2113STRPBF

Package：

SOIC-16W

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

OC5A2B00

NCV887103D1R2G

NAE12S17-A

MIC4428YM

MIC2951-03BN

LTM4673Y

LTC3780IG

LTC3112EFE

Description

Product Overview

The IR2113STRPBF is a high-performance 600V high-side and low-side gate driver IC from Infineon Technologies’ EiceDRIVER™ family. With 2.5A source/sink output current, matched propagation delays, and shutdown feature, this driver is ideal for driving IGBTs and MOSFETs in demanding half-bridge and full-bridge applications.

Key Specifications

Manufacturer Infineon Technologies
Device Type High/Low Side Gate Driver w/ Shutdown
V_OFFSET 600 V (max)
Output Current (Source/Sink) 2.5 A / 2.5 A (typ)
Supply Voltage Range 10 V to 20 V
UVLO Threshold (VBS) 8.6 V (on) / 8.2 V (off)
Propagation Delay 120 ns (on) / 94 ns (off)
Delay Matching 20 ns (max)
Input Logic 3.3V CMOS compatible
Package SOIC-16W
Operating Temperature -40°C to +125°C

Features

  • Floating channel for bootstrap operation up to 600V
  • 2.5A peak source and sink drive current
  • Negative transient tolerant, dV/dt immune
  • Gate drive supply: 10V to 20V
  • Undervoltage lockout for both channels
  • 3.3V logic compatible, separate logic supply
  • CMOS Schmitt-triggered inputs
  • Matched propagation delay (20ns max)
  • Cycle-by-cycle edge-triggered shutdown
  • RoHS compliant, SOIC-16W package

Applications

  • IGBT and MOSFET gate drive
  • AC and BLDC motor drives
  • UPS and inverter systems
  • Solar inverters
  • Welding equipment
  • Industrial power supplies
  • DIN rail power supply solutions
  • Photovoltaic systems

The IR2113STRPBF is an EiceDRIVER™ 600V high-side and low-side gate driver IC from Infineon Technologies, designed for driving IGBTs and MOSFETs in high-voltage power conversion applications. With typical 2.5A source and 2.5A sink current capability in a 16-lead SOICWB package, this driver delivers robust gate drive performance for medium to high power systems. The IR2113S features independent high-side and low-side channels with matched propagation delays (20ns max mismatch), enabling precise timing control in high-frequency applications. The shutdown pin provides cycle-by-cycle edge-triggered protection. The floating channel supports bootstrap operation up to 600V, with tolerance to negative transients and high dV/dt conditions.

The IR2113STRPBF uses high-voltage level-shift technology built on Infineon’s proprietary HVIC and latch-immune CMOS process. The HIN and LIN logic inputs independently control the high-side (HO) and low-side (LO) gate drive outputs respectively. A separate shutdown (SD) input can force both outputs low, providing system-level protection with edge-triggered cycle-by-cycle operation. The high-side driver is powered by a bootstrap capacitor between VB and VS, with undervoltage lockout (UVLO) monitoring both the high-side bootstrap supply and the low-side VCC supply. Separate VDD/VSS logic supply pins allow the input interface to operate at different voltage levels from the power stage, with up to ±5V offset between logic ground and power ground.

Pin Number Pin Name Function
1 LO Low-Side Gate Drive Output
2 VCC Low-Side Power Supply (10-20V)
3 VB High-Side Floating Supply (Bootstrap)
4 HO High-Side Gate Drive Output
5 VS High-Side Floating Return
6-8 NC No Connection
9 VDD Logic Supply Voltage (3.3-20V)
10 HIN High-Side Input (Logic)
11 LIN Low-Side Input (Logic)
12 SD Shutdown Input (Active High)
13-14 NC No Connection
15 VSS Logic Ground
16 COM Power Ground
  • IGBT and power MOSFET gate drive circuits
  • AC induction and BLDC motor drive inverters
  • Uninterruptible power supply systems
  • Photovoltaic solar inverters
  • Welding power supplies
  • Industrial power converters
  • DIN rail power supply solutions
  • Full-bridge and half-bridge topologies
Model Manufacturer Description
IR2110STRPBF Infineon 500V version, 2A drive
IR2113PBF Infineon PDIP-14 through-hole version
IRS2113STRPBF Infineon IRS series enhanced version
