IR21844STRPBF

Infineon IR21844STRPBF half-bridge gate driver, 600V, 1.4A/1.8A, programmable dead time, SOIC-14

5670

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

IR21844STRPBF

Package：

SOIC-14

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

OC5A2B00

NCV887103D1R2G

NAE12S17-A

MIC4428YM

MIC2951-03BN

LTM4673Y

LTC3780IG

LTC3112EFE

Description

Product Overview

The IR21844STRPBF is a high-voltage half-bridge gate driver IC from Infineon Technologies with programmable dead time and separate logic ground. This 600V driver features IN/SD single-input control with shutdown capability, making it ideal for half-bridge converters requiring adjustable dead time.

Key Specifications

Manufacturer Infineon Technologies
Device Type Half-Bridge Gate Driver (Programmable DT)
V_OFFSET 600 V (max)
Output Current (Source/Sink) 1.4 A / 1.8 A (typ)
Supply Voltage Range 10 V to 20 V
Dead Time Programmable 0.4 µs to 5 µs
Propagation Delay 680 ns (on) / 270 ns (off)
Input Logic 3.3V / 5V compatible
Separate Logic Ground Yes (VSS pin)
Package SOIC-14
Operating Temperature -40°C to +125°C

Features

  • Floating channel for bootstrap operation up to 600V
  • Programmable dead time: 0.4µs to 5µs
  • Single IN/SD input with shutdown mode
  • Output source/sink: 1.4A/1.8A
  • dV/dt immune, negative transient tolerant
  • Undervoltage lockout for both channels
  • 3.3V and 5V input logic compatible
  • Matched propagation delay
  • Lower di/dt for better noise immunity
  • RoHS compliant, SOIC-14 package

Applications

  • Half-bridge DC-DC converters
  • Resonant converter topologies
  • Motor drives
  • Switch-mode power supplies
  • Electronic ballasts
  • LED drivers
  • UPS systems
  • Industrial power supplies

The IR21844STRPBF is a high-voltage, high-speed power MOSFET and IGBT driver with dependent high-side and low-side referenced output channels from Infineon Technologies. Built on proprietary HVIC and latch-immune CMOS technology, this device provides a rugged monolithic half-bridge driver solution with programmable dead time. A single input pin (IN/SD) controls both channels with complementary output and built-in cross-conduction prevention logic. Dead time is user-programmable from 0.4µs to 5µs via an external resistor on the DT pin, offering flexibility for different power devices and switching frequencies. Separate VSS logic ground pin allows ±5V offset between logic and power grounds for improved noise immunity in high-current applications.

The IR21844STRPBF operates as a complementary-output half-bridge gate driver with programmable dead time. When the IN input is high, the low-side output (LO) is high and the high-side output (HO) is low. When IN goes low, after a delay determined by the programmed dead time, LO goes low and HO goes high. The dead time is set by an external resistor connected to the DT pin, with a range from approximately 400ns to 5µs. The high-side driver uses bootstrap technique with a floating channel rated for up to 600V offset voltage. The SD function is integrated into the IN pin – when pulled below the low-level threshold, both outputs eventually go low with the low side turning off first. UVLO circuitry monitors both VCC and the bootstrap supply.

Pin Number Pin Name Function
1 VCC Low-Side Power Supply (10-20V)
2 HO High-Side Gate Drive Output
3 VB High-Side Floating Supply (Bootstrap)
4 DT Dead Time Programming Resistor
5 IN Logic Input / Shutdown
6 VSS Logic Ground
7 NC No Connection
8 NC No Connection
9 COM Power Ground
10 LO Low-Side Gate Drive Output
11 VS High-Side Floating Return
12-14 NC No Connection

Note: Exact pinout may vary by package variant; typical SOIC-14 arrangement shown.

  • Half-bridge DC-DC and AC-DC converters
  • LLC and resonant converter topologies
  • Motor drive and control circuits
  • Switch-mode power supplies
  • Electronic lamp ballasts
  • LED driver power stages
  • Uninterruptible power supplies
  • Industrial power converters
