IRS2092STRPBF

IRS2092STRPBF - Protected Class D Audio Amplifier Driver (Tape & Reel), SOIC-16 Narrow (Tape & Reel)

2947

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

IRS2092STRPBF

Package：

SOIC-16 Narrow (Tape & Reel)

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

M65847AFP

PDZ33B,115

TDZ4V7J,115

ERZE11A621

PESD1LIN,115

SMBJ20CA

NRVUS110VT3G

FDMC2523P

Description

Product Overview

The IRS2092STRPBF is a Protected Class D Audio Amplifier Driver (Tape & Reel) from Infineon Technologies (formerly International Rectifier). Built using HVIC Technology, this device combines a high-voltage gate driver with integrated PWM modulator and comprehensive protection features in a compact SOIC-16 Narrow (Tape & Reel) package. When paired with external power MOSFETs, the IRS2092STRPBF forms a complete, high-performance Class D audio amplifier solution.

The IRS2092STRPBF leverages proprietary noise isolation technology that allows the high-current gate drive stage and high-speed low-noise error amplifier to coexist on a single silicon die. The open PWM modulator architecture provides design flexibility for various PWM topology implementations, making it suitable for a wide range of audio power amplifier applications.

Key Specifications

Supply Voltage Range (VCC) VCC: 10V to 18V
Floating Voltage Rating ±100V (floating rating)
Output Current (Source / Sink) Output: 1.0A source / 1.2A sink
Maximum Output Power Up to 500W (4Ω load)
Switching Frequency Up to 800 kHz
THD+N (1kHz, 50W, 4Ω) 0.01% (typical)
Operating Temperature Range -40 to +125 °C
Package SOIC-16 Narrow (Tape & Reel)

Features

  • Integrated analog input Class D audio amplifier driver
  • THD+N 0.01%, programmable deadtime, click noise reduction, up to 500W output
  • Floating PWM input for easy half-bridge implementation
  • Programmable over-current protection with self-reset
  • Programmable preset dead-time for improved THD
  • Start and stop click noise reduction
  • High noise immunity
  • 3.3V/5V logic compatible input
  • Lead-free, halogen-free, RoHS compliant
  • SOIC-16 Narrow (Tape & Reel) surface mount package

Applications

  • Home theater systems, powered speaker systems, 500W mono Class-D amplifiers
  • Home theater systems
  • Mini-component stereo systems
  • Powered speaker systems
  • General purpose audio power amplifiers
  • Automotive head units
  • In-vehicle infotainment systems

The IRS2092STRPBF is a high voltage, high performance Class D audio amplifier driver with integrated PWM modulator and protection from Infineon Technologies. In conjunction with two external MOSFETs and a few external components, a complete Class D audio amplifier with comprehensive protection can be realized. The device features thd+n 0.01%, programmable deadtime, click noise reduction, up to 500w output, making it ideal for home theater systems, powered speaker systems, 500w mono class-d amplifiers. With ±100V (floating rating) floating voltage rating, it can deliver up to 500W of output power.

The IRS2092STRPBF operates as a self-oscillating Class D audio amplifier driver. The analog input section includes an error amplifier that compares the audio input signal with the output feedback, generating an error signal that feeds into a PWM comparator. The PWM modulator converts this analog signal into a high-frequency pulse-width modulated waveform that drives both high-side and low-side gate driver outputs. The integrated protection features include dual over-current protection (OCP) with self-reset, shoot-through protection, and undervoltage lockout (UVLO) for all three bias supplies. The programmable dead-time prevents cross-conduction while optimizing THD performance. The floating architecture allows direct high-side gate drive without requiring an external level shifter.

Pin Number Pin Name Description
1 VAA Floating input positive supply
2 GND Floating input supply return
3 IN- Analog inverting input
4 COMP Phase compensation / comparator input
5 CSD Shutdown timing capacitor
6 VSS Floating input negative supply
9 DT Deadtime program input
10 COM Low side supply return
11 LO Low side gate drive output
12 VCC Low side supply
13 VS High side floating supply return
15 VB High side floating supply
16 CSH High side current sense input
  • Home theater systems, powered speaker systems, 500W mono Class-D amplifiers
  • Home theater systems
  • Mini-component stereo systems
  • Powered speaker systems
  • General purpose audio power amplifiers
  • Automotive head units
  • In-vehicle infotainment & HMI
Model Description Package
IRS2092SPBF Same die, tube/bulk packaging SOIC-16
IRS2092PBF Through-hole PDIP-16 package PDIP-16
Recommend Parts
