IRS2104STRPBF

600V half-bridge gate driver with shutdown, 0.27A/0.6A, SOIC-8, dead time

9523

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

IRS2104STRPBF

Package：

SOIC-8N (4.9 x 3.9 x 1.5 mm)

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

OC5A2B00

NCV887103D1R2G

NAE12S17-A

MIC4428YM

MIC2951-03BN

LTM4673Y

LTC3780IG

LTC3112EFE

Description

Product Overview

The IRS2104STRPBF is a 600V high-side and low-side gate driver IC with shutdown function, manufactured by Infineon Technologies. Available in an 8-lead SOIC-8N package, this half-bridge driver features a single PWM input with complementary outputs, integrated dead time, and an active-low shutdown pin. Based on Infineon’s HVIC technology, the IRS2104 provides robust, high-speed operation with dV/dt immunity and negative transient voltage tolerance. The shutdown function allows both outputs to be disabled simultaneously, providing a convenient fault protection mechanism. Undervoltage lockout ensures reliable operation under all supply conditions.

Key Specifications

Manufacturer Infineon Technologies
Product Type Half-Bridge Gate Driver with Shutdown
Voltage Rating 600 V
Configuration High + Low Side (Half-Bridge)
Number of Inputs 1 PWM + 1 Shutdown
Output Current (Source) 0.13 A / 0.27 A (IO+)
Output Current (Sink) 0.27 A / 0.6 A
Supply Voltage (Vcc) 10 V to 20 V
Dead Time Integrated (typ 525 ns)
UVLO Threshold 8.2 V (falling) / 8.9 V (rising)
Turn-on Delay 680 ns (typ)
Turn-off Delay 180 ns (typ)
Logic Input Compatibility 3.3 V / 5 V / 15 V
Shutdown Active low (SD pin)
dV/dt Immunity High
Operating Temperature -40°C to +150°C (TJ)
Package SOIC-8N
Packaging Tape & Reel (2500 units/reel)

Features

  • Floating channel for bootstrap operation up to 600V
  • Single PWM input with complementary outputs and built-in dead time
  • Active-low shutdown input (SD pin) disables both outputs
  • dV/dt immune and negative transient voltage tolerant
  • Gate drive supply range: 10 V to 20 V
  • Undervoltage lockout (UVLO) for both channels
  • 3.3 V, 5 V, and 15 V logic input compatible
  • Latch-immune CMOS construction
    • Matched propagation delay between channels
  • RoHS compliant and lead-free

Applications

  • Motor control and variable speed drives
  • Switch-mode power supplies (SMPS)
  • DC-DC converters with half-bridge topology
  • Lighting ballasts (fluorescent, HID)
  • Industrial power conversion
  • Home appliances and white goods

The IRS2104STRPBF is a high-performance 600V half-bridge gate driver IC from Infineon Technologies, featuring integrated dead-time generation and an active-low shutdown function. This device simplifies half-bridge designs by accepting a single PWM input and generating complementary high-side and low-side drive signals with built-in dead time, eliminating the need for external dead-time circuitry. The shutdown (SD) pin provides a fast, convenient way to disable both outputs simultaneously, making it ideal for fault protection and emergency stop functions. Built on Infineon’s proven HVIC technology platform with latch-immune CMOS construction, the IRS2104 delivers high dV/dt immunity and tolerance to negative transient voltages, ensuring robust performance in demanding switching environments. Undervoltage lockout (UVLO) protects against under-driven gate conditions on both channels. With 3.3V/5V/15V compatible logic inputs, the device interfaces easily with microcontrollers, DSPs, and analog control circuits. Supplied in a compact SOIC-8N package with tape and reel packaging, the IRS2104STRPBF is suitable for a wide range of applications including motor drives, power supplies, lighting ballasts, and industrial inverters.

The IRS2104STRPBF functions as a half-bridge gate driver with shutdown and dead-time integration. Its architecture consists of: 1) Input Control Logic: The device accepts a single PWM input (IN pin) and an active-low shutdown input (SD pin). The IN signal controls the half-bridge switching, with the high-side output being in phase and the low-side output being out of phase after dead-time insertion. When SD is pulled low, both outputs are forced low (shutdown state). 2) Dead-Time Generation: An integrated dead-time generator inserts a fixed dead time (typically 525ns) between the high-side and low-side switching transitions, ensuring both power MOSFETs/IGBTs are never on simultaneously. This prevents shoot-through currents that could damage the power devices. 3) HVIC Level Shifter: Proprietary high-voltage IC technology level-shifts the high-side control signal from the low-voltage domain to the floating high-side domain operating at up to 600V offset. The level shifter is dV/dt immune and tolerant of negative voltage transients. 4) Output Drivers and Protection: Both high-side (HO) and low-side (LO) outputs provide gate drive current to power MOSFETs or IGBTs. Undervoltage lockout (UVLO) circuits monitor VCC and VBS supplies, disabling outputs if voltages drop below safe thresholds. The shutdown function overrides normal operation for fast fault response.

Pin Name Type Function
1 VB Power High-side floating supply voltage (bootstrap)
2 HO Output High-side gate driver output
3 VS Power High-side floating supply return / switch node
4 COM Ground Low-side return / signal ground
5 LO Output Low-side gate driver output
6 VCC Power Low-side and logic supply (10-20V)
7 IN Input PWM logic input (controls both outputs)
8 SD Input Shutdown input (active low)
  • AC induction motor and BLDC motor control systems
  • Half-bridge and full-bridge DC-DC power converters
  • Switch-mode power supplies with fault protection
  • Fluorescent lamp and HID lighting ballasts
  • Uninterruptible power supplies (UPS)
  • Industrial motor drives and inverters
  • Home appliance compressor and fan controllers
Manufacturer Part Number Package Notes
Infineon IRS2101STRPBF SOIC-8 Dual input, no shutdown/dead time
Infineon IRS2103STRPBF SOIC-8 Single input with dead time, no shutdown
STMicroelectronics L6386ED SOIC-8 High-low side driver with SD
Texas Instruments UCC27210A SOIC-8 120V half-bridge with disable
Microchip MIC4104 SOIC-8 Dual MOSFET driver with enable
