ISL95855HRTZ-T

IMVP8 3+2+1 phase buck controller, R3 technology, 4.5-25V input, 48-TQFN

2156

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

ISL95855HRTZ-T

Package：

48-TQFN (6x6 mm, exposed pad)

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

OC5A2B00

NCV887103D1R2G

NAE12S17-A

MIC4428YM

MIC2951-03BN

LTM4673Y

LTC3780IG

LTC3112EFE

Description

Product Overview

The ISL95855HRTZ-T is a 3+2+1 voltage regulator controller designed for Intel IMVP8™ CPUs, manufactured by Renesas Electronics (formerly Intersil). Based on Intersil’s proprietary Robust Ripple Regulator (R3™) technology, this device provides a complete power solution for Intel microprocessors, supporting core, graphics, and system agent power rails. The ISL95855 features three output controllers: VRA (configurable 3/2/1 phase), VRB (configurable 2/1 phase), and VRC (1 phase). It supports Intel Serial Data Bus (SVID) interface for communication with the CPU, system input power monitoring (PSYS), and multiple current sensing methods including lossless inductor DCR and precision resistor sensing.

Key Specifications

Manufacturer Renesas Electronics (Intersil)
Product Type IMVP8 CPU Voltage Regulator Controller
Regulation Topology Buck PWM (R3™ Technology)
Number of Outputs 3 (VRA + VRB + VRC)
Input Voltage Range 4.5 V to 25 V
Output Voltage Range 0 V to 1.52 V
VRA Phases Configurable 1, 2, or 3 phases
VRB Phases Configurable 1 or 2 phases
VRC Phases 1 phase (fixed)
Control Interface Intel SVID (Serial Voltage Identification)
System Accuracy 0.5%
Current Sensing DCR or Resistor
Power Monitoring PSYS (System Input Power)
Features Differential remote sensing, OVP, OCP
Status Obsolete / Not for new designs
Package 48-TQFN (6×6 mm, exposed pad)
Operating Temperature -40°C to +100°C

Features

  • Supports Intel IMVP8™ protocol with SVID interface
  • 3+2+1 multi-phase buck controller configuration
  • R3™ (Robust Ripple Regulator) technology for fast transient response
  • System input power monitoring (PSYS)
  • 0.5% system accuracy over temperature
  • Low quiescent current in PS4 state
  • Supports both DCR and resistor current sensing methods
  • Differential remote voltage sensing for load line regulation
  • Programmable SVID address, VBOOT voltage, and switching frequency
  • Comprehensive protection: OVP, OCP, UVP, OTP

Applications

  • Notebook computers with Intel IMVP8 CPUs
  • Desktop computers and all-in-one PCs
  • Ultrabooks and tablet computers
  • High-performance computing platforms
  • Server and workstation power supplies
  • Graphics card power regulation

The ISL95855HRTZ-T is a multi-phase pulse-width modulation (PWM) controller designed for Intel IMVP8 compliant microprocessor power supplies. Manufactured by Renesas Electronics (formerly Intersil), this device features Intersil’s patented R3™ (Robust Ripple Regulator) technology, which combines the best features of fixed-frequency PWM and hysteretic PWM while eliminating many of their shortcomings. The R3™ technology provides very fast transient response with reduced output capacitance requirements. The ISL95855 provides three independently controlled output voltages: VRA (core rail, configurable for 3, 2, or 1 phase), VRB (graphics rail, configurable for 2 or 1 phase), and VRC (system agent rail, 1 phase). All three rails communicate with the CPU via the Intel Serial Voltage Identification (SVID) bus. The device supports system input power monitoring (PSYS) and features 0.5% system accuracy over temperature. Current sensing can be implemented using either lossless inductor DCR sensing or precision resistor sensing for maximum flexibility. Differential remote voltage sensing ensures accurate voltage regulation at the load point. Comprehensive protection features include over-voltage protection (OVP), over-current protection (OCP), under-voltage protection (UVP), and thermal shutdown. The ISL95855HRTZ-T is supplied in a thermally enhanced 48-lead TQFN package with exposed pad for efficient heat dissipation.

The ISL95855HRTZ-T operates as a multi-phase buck regulator controller using R3™ technology for Intel IMVP8 CPU power delivery. Its core operation includes: 1) R3™ Modulation Technology: Unlike conventional PWM controllers, the R3™ (Robust Ripple Regulator) modulator synthesizes an AC ripple signal and compares it with an error amplifier output. This architecture combines the advantages of fixed-frequency PWM (constant switching frequency, good noise characteristics) with hysteretic PWM (fast transient response, no compensation network needed). 2) Multi-Phase Control: The VRA (core) rail supports 1-3 phases, VRB (graphics) supports 1-2 phases, and VRC (system agent) is a single phase. Phase shedding dynamically reduces active phases at light loads to improve efficiency. A current sharing loop ensures balanced current among phases. 3) SVID Interface: The Intel Serial Voltage Identification (SVID) interface allows the CPU to dynamically request different output voltages and operating states (including PS1, PS2, PS3, and PS4 power states). The controller responds to SVID commands by adjusting the output voltage and managing phase count. 4) Current Sensing and Monitoring: Both DCR (inductor DC resistance) and resistor current sensing methods are supported. The PSYS function monitors total system input power by summing the power of all active rails, enabling accurate system power budgeting and thermal management. 5) Protection System: Comprehensive protection includes over-voltage protection (OVP) with fast response, per-phase and total over-current protection (OCP), under-voltage protection (UVP), and thermal shutdown. These features protect both the regulator and the load from fault conditions.

Pin Group Function Description
PVCC/VDDP Power Internal 5V linear regulator input (4.5V-25V)
PVCC/3V3 Power 3.3V internal supply for logic
GNDA/GND Ground Analog and power ground connections
SDA/SCL/ALERT# SVID Interface Intel SVID serial data, clock, and alert pins
PWM1-PWM6 PWM Outputs PWM outputs for external drivers (6 channels)
ISENA-ISENF Current Sense Current sense inputs for each phase (6 channels)
VSEN_A/B/C Voltage Sense Output voltage sense for each rail (differential)
IMON/PSYS Monitor Current monitor and system power monitor outputs
TON/SETx Configuration Switching frequency and phase configuration pins
EN/VBOOT Control Enable and VBOOT setting pins
PGOOD Status Power good output signal
  • Intel IMVP8-compliant notebook computer CPU power supplies
  • Desktop PC and all-in-one computer VRMs
  • Ultrabook and tablet computer power regulation
  • High-performance workstation CPU power delivery
  • Server processor power modules
  • Multi-rail power supply for graphics-intensive systems
Manufacturer Part Number Package Notes
Renesas ISL95855AHRTZ-T 48-TQFN Variant A, IMVP8
Renesas ISL95829AHRTZ-T 48-TQFN IMVP8 controller, 3+2 output
Texas Instruments TPS51624 40-VQFN IMVP8 V-Core controller
Analog Devices ADP5064 48-LFCSP Multi-phase buck controller
Richtek RT3600AJ 40-QFN IMVP8 dual PWM controller
