NCV887103D1R2G

Automotive boost controller, 3.2-40V input, 340kHz, peak current mode, AEC-Q100, SOIC-8

10000

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

NCV887103D1R2G

Package：

SOIC-8 (4.9 x 3.9 x 1.5 mm, 1.27mm pitch)

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

OC5A2B00

NAE12S17-A

MIC4428YM

MIC2951-03BN

LTM4673Y

LTC3780IG

LTC3112EFE

LTC2955CTS8-1

Description

Product Overview

The NCV887103D1R2G is an automotive-grade non-synchronous boost controller from ON Semiconductor. Designed for automotive and other high-voltage applications, this peak current mode controller operates from 3.2V to 40V input (45V load dump tolerant) and features fixed frequency operation at 340kHz. Packaged in SOIC-8, the NCV887103 is ideal for automotive applications such as LED drivers, automotive audio systems, and start-stop system power supplies.

Key Specifications

Manufacturer ON Semiconductor
Type Non-Synchronous Boost DC-DC Controller
Topology Boost (Step-Up), Flyback capable
Input Voltage Range 3.2V to 40V (45V load dump)
Switching Frequency 340 kHz (fixed)
Reference Voltage 1.2V ± 2%
Control Method Peak Current Mode with Slope Compensation
Duty Cycle (Max) 93%
Gate Drive Current 575 mA peak source/sink
Oscillator Sync Yes (external sync capable)
Quiescent Current 3 mA typical operating
Sleep Mode Current 100 µA
Operating Temperature -40°C to +150°C (Tj)
Package SOIC-8 (3.90mm width)
Automotive Grade AEC-Q100 Qualified
Protection UVLO, OCP (hiccup), SCP (hiccup), TSD

Features

  • AEC-Q100 qualified (Grade 1 automotive)
  • Wide input voltage: 3.2V to 40V (45V load dump)
  • Peak current mode control with internal slope compensation
  • Fixed 340kHz switching frequency
  • External frequency synchronization
  • Internal soft-start
  • Low quiescent current sleep mode (100µA)
  • Cycle-by-cycle current limit
  • Hiccup-mode overcurrent and short-circuit protection
  • Thermal shutdown (TSD)
  • Undervoltage lockout (UVLO)
  • 575mA gate drive capability
  • SOIC-8 surface-mount package

Applications

  • Automotive LED headlight drivers
  • Automotive audio power supplies
  • Start-stop system DC-DC converters
  • Industrial boost converters
  • Flyback power supplies
  • Battery-powered system boost regulators
  • Automotive instrumentation and dashboard power
  • Telecom and networking power

The NCV887103D1R2G is an automotive-grade non-synchronous boost (step-up) DC-DC controller from ON Semiconductor. Designed specifically for automotive applications, this controller is AEC-Q100 qualified and PPAP capable, ensuring it meets the rigorous quality and reliability standards of the automotive industry. The NCV8871 series uses peak current mode control with internal slope compensation for stable operation over a wide range of input and output conditions. The ’03’ in the part number indicates a 340kHz fixed switching frequency version, while the ‘D’ suffix specifies SOIC-8 package. The wide input voltage range of 3.2V to 40V (with 45V load dump tolerance) makes this device suitable for automotive 12V systems where input voltage can vary widely during cold crank, load dump, and start-stop operation. The controller drives an external N-channel MOSFET, allowing the power stage to be sized for the specific application requirements. Key features include internal soft-start for controlled startup, undervoltage lockout (UVLO) for proper operation at low input voltages, and comprehensive protection including cycle-by-cycle current limiting, hiccup-mode overcurrent and short-circuit protection, and thermal shutdown. The low quiescent current sleep mode (100µA) is useful for battery-powered systems that need to minimize standby power consumption. The NCV887103D1R2G can also be used in flyback converter configurations, adding versatility for isolated power supply designs.

The NCV887103D1R2G operates as a peak current mode controlled boost (step-up) DC-DC controller: 1) Oscillator and Timing: The internal oscillator generates a fixed 340kHz clock that sets the switching frequency. The oscillator can also be synchronized to an external clock signal via the SYNC pin for applications requiring frequency synchronization. 2) Error Amplifier and Compensation: An error amplifier compares the feedback voltage (sensed from the output through a resistor divider) to the 1.2V internal reference voltage. The output of the error amplifier (COMP pin) sets the peak current threshold for each switching cycle. 3) Current Mode Control: At the start of each clock cycle, the external MOSFET is turned on. The inductor current ramps up, and this current is sensed (through a sense resistor in series with the MOSFET source). When the sensed current reaches the threshold set by the error amplifier, the MOSFET is turned off. This is peak current mode control. Internal slope compensation adds a stabilizing ramp to the current sense signal to prevent sub-harmonic oscillation at duty cycles above 50%. 4) Gate Drive: The GATE pin directly drives the gate of the external N-channel MOSFET. The gate driver provides 575mA of peak drive current for fast switching transitions. 5) Output Diode: When the MOSFET is off, the inductor current flows through an external Schottky diode (non-synchronous) to charge the output capacitor and supply the load. 6) Soft-Start: An internal soft-start circuit gradually increases the current limit during startup, preventing excessive inrush current and output voltage overshoot. 7) Protection: – UVLO: Ensures the controller only operates when VCC is above the minimum threshold. – OCP/SCP: Cycle-by-cycle current limit prevents excessive current; hiccup mode provides short-circuit protection. – TSD: Thermal shutdown protects the IC from overheating. 8) Sleep Mode: When the EN/UVLO pin is pulled low, the controller enters a low-power sleep mode with only 100µA quiescent current, preserving battery life.

Pin Name Type Function
1 GATE Output Gate drive output for external N-MOSFET
2 VCC Power Supply voltage (3.2-40V)
3 CS Input Current sense input
4 FB Input Feedback voltage input
5 COMP I/O Error amplifier output (compensation network)
6 SYNC/RT I/O External sync / Oscillator timing
7 EN/UVLO Input Enable / Undervoltage lockout adjustment
8 GND Ground Ground
  • Automotive LED headlight and daytime running light drivers
  • Automotive audio system power supplies
  • Start-stop system auxiliary power converters
  • Automotive instrumentation backlighting and dashboard power
  • Industrial boost converters for 12V to 24V/48V
  • Flyback converters for isolated auxiliary supplies
  • Battery-powered system boost regulators
  • Telecom power supply 24V or 48V bus generation
Manufacturer Part Number Package Notes
ON Semiconductor NCV887100D1R2G SOIC-8 Standard version (not auto grade)
ON Semiconductor NCV887104D1R2G SOIC-8 Different frequency variant
TI LM3481-Q1 SOT-23-6 Automotive boost controller
Analog Devices LT3757-1 MSOP-10 Boost/SEPIC/FLYBACK controller
Maxim MAX1771 SOIC-8 Boost controller alternative
