Product Overview
The MX25L4006EZUI-12G is a 4Mbit serial NOR Flash memory from Macronix with Dual Output mode support. It features standard SPI interface operating at up to 86MHz clock frequency in single I/O mode and 80MHz in Dual Output mode. The device comes in an 8-USON (2x3mm) ultra-small package, operates from 2.7V to 3.6V, and supports industrial temperature range. With 4KB uniform sectors and hardware/software protection features, it provides compact non-volatile storage for space-constrained embedded applications.
Key Specifications
| Memory Type | FLASH – NOR (Non-Volatile) |
| Memory Size | 4Mbit (512K x 8) |
| Interface | SPI (Dual Output) |
| Clock Frequency | 86 MHz (x1), 80 MHz (Dual Output) |
| Voltage Supply | 2.7V ~ 3.6V |
| Operating Temperature | -40°C ~ 85°C |
| Package | 8-USON (2x3mm) |
| Page Size | 256 bytes |
| Endurance | 100,000 cycles |
| Data Retention | 20 years |
Features
- Standard SPI interface with Dual Output mode
- Fast read: 86MHz single, 80MHz dual output
- 4Mbit density: 512K x 8 organization
- Uniform 4KB sectors (128 sectors)
- Uniform 64KB blocks (8 blocks)
- Page program: 256 bytes per page
- Hardware write protection (WP# pin)
- Software block protection (BP0-BP2)
- Deep power-down mode
- Hardware HOLD# function
- Low power CMOS design
- Ultra-small 8-USON 2x3mm package
- JEDEC standard ID
- RoHS compliant and halogen-free
Applications
- Ultra-compact embedded systems
- Wearable electronics
- IoT sensors and modules
- Consumer electronics
- Medical devices
- Bluetooth and WiFi modules
- Smart cards and secure elements
- Configuration memory for small FPGAs
