MX25U51245GMI00

512Mbit 1.8V SPI NOR Flash, Quad I/O, DTR, 133MHz, 16-SOP, Industrial Grade

2890

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

MX25U51245GMI00

Package：

16-SOP

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

MSP430F5304IRGZR

MS9282-1

OP2177ARMZ

NJM2068M

NCF3320EHN

NC7SZ126M5X

MT8870DSR1

MCP6S26-I

Description

Product Overview

The MX25U51245GMI00 is a 512Mbit 1.8V multi-I/O SPI NOR Flash memory from Macronix’s MXSMIO™ Duplex (DTR) series. It features Single I/O, Dual I/O, and Quad I/O interfaces with Double Transfer Rate (DTR) mode, providing data transfer rates up to 400MHz — making it one of the fastest serial NOR Flash devices in the industry. The device comes in a 300mil 16-SOP package, operates from 1.65V to 2.0V supply voltage, and supports industrial temperature range of -40°C to +85°C. It is in production status and recommended for new designs.

Key Specifications

Memory Type FLASH – NOR (Non-Volatile)
Memory Size 512Mbit (64M x 8)
Interface SPI – Quad I/O, QPI, DTR
Clock Frequency 166MHz (x1/x2), 133MHz (x4)
DTR Mode Up to 400MHz equivalent
Voltage Supply 1.65V ~ 2.0V (1.8V nominal)
Operating Temperature -40°C ~ 85°C
Package 16-SOP (300mil)
Process Node Advanced (45nm class)
Endurance 100,000 cycles typical

Features

  • MXSMIO™ Duplex (DTR) series – industry’s fastest serial NOR
  • Single I/O, Dual I/O, Quad I/O, and QPI support
  • Double Transfer Rate (DTR) mode operation
  • Multi-I/O default enable – no Quad Enable register configuration needed
  • Fast Boot mode for XIP (execute-in-place)
  • Program/Erase Suspend and Resume
  • Burst Read with wrap-around
  • Advanced Sector Protection (Individual + Password)
  • Secured OTP memory
  • Hardware Reset support
  • Unique ID feature
  • 4-byte address mode for 512Mb density
  • SFDP (Serial Flash Discoverable Parameters) compliant
  • Deep power-down mode
  • RoHS compliant and halogen-free

Applications

  • High-density code storage for embedded systems
  • Industrial control and automation
  • Automotive electronics (infotainment, ADAS)
  • Networking and telecom equipment
  • Set-top boxes and digital TVs
  • Medical devices
  • Aerospace and defense systems
  • Data center and storage systems

The MX25U51245GMI00 is a 512Mbit 1.8V CMOS serial multi-I/O NOR Flash memory from Macronix’s MXSMIO™ Duplex (DTR) series. It is part of the MX25_45 generation featuring advanced process technology and Multi-I/O default enable, allowing Quad mode read instructions to be executed directly without configuring the Quad Enable register. The device supports Single I/O, Dual I/O, and Quad I/O modes, along with QPI (Quad Peripheral Interface) and DTR (Double Transfer Rate) mode for maximum throughput. DTR mode enables data transfer on both edges of the clock, effectively doubling the data rate compared to STR (Single Transfer Rate) mode. The 512Mbit memory uses 4-byte addressing and features uniform 4KB sectors, 32KB blocks, and 64KB blocks. Advanced features include Fast Boot for XIP applications, Program/Erase Suspend/Resume, Burst Read, Advanced Sector Protection with individual and password protection, Secured OTP, hardware reset, and Unique ID. The 16-pin 300mil SOP package provides a standard, high-density form factor. Operating from 1.65V to 2.0V over industrial temperature range, it is ideal for high-performance 1.8V systems.

The MX25U51245G operates as a high-speed 1.8V serial NOR Flash using advanced Multi-I/O SPI protocol with DTR capability. In standard SPI mode, commands are sent on SI and data received on SO, with clock rates up to 166MHz. In Quad I/O mode, all four data pins carry data simultaneously, achieving much higher throughput. DTR (Double Transfer Rate) mode further enhances performance by transferring data on both rising and falling edges of the clock, effectively doubling the data rate. The device uses 4-byte addressing to access the full 512Mbit memory space, with commands available for both 3-byte and 4-byte address modes. An internal state machine manages all program and erase operations automatically. Program/Erase Suspend/Resume allows temporarily halting operations to access other memory regions. Advanced sector protection provides both individual sector/block protection and password-protected access control. The Multi-I/O default enable feature means Quad mode is available immediately after power-up, eliminating the need to set a QE bit, simplifying system design and improving reliability.

Pin Number Pin Name Type Description
1 NC/SIO3 I/O No Connect / I/O3 (alternate assignment)
2 VCC Power Power supply 1.65V-2.0V
3 VCC Power Power supply (internal connection)
4-7 NC – No internal connections
8 RESET#/SIO3 I/O Hardware Reset / I/O3 in quad/QPI/DTR mode
9 GND Ground Ground connection
10 WP#/SIO2 I/O Write Protect / I/O2 in quad/QPI mode
11 SCLK Input Serial Clock input
12 SI/SIO0 I/O Serial Input / I/O0
13 SO/SIO1 I/O Serial Output / I/O1
14-15 NC – No internal connections
16 CS# Input Chip Select, active low
