MX25U6432FM2I02

64Mbit 1.8V SPI NOR Flash, Quad I/O, QPI, 133MHz, 75nm, 8-SOP

8765

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

MX25U6432FM2I02

Package：

8-SOP

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

MSP430F5304IRGZR

MS9282-1

OP2177ARMZ

NJM2068M

NCF3320EHN

NC7SZ126M5X

MT8870DSR1

MCP6S26-I

Description

Product Overview

The MX25U6432FM2I02 is a 64Mbit 1.8V multi-I/O SPI NOR Flash memory from Macronix. Part of the MX25U series, it is specifically designed for 1.8V low-voltage systems, supporting Single I/O, Dual I/O, and Quad I/O operations up to 133MHz clock frequency. The device features QPI (Quad Peripheral Interface) mode, Program/Erase Suspend/Resume, Advanced Sector Protection, and Secured OTP. Packaged in 200mil 8-SOP, it operates over industrial temperature range and is manufactured using 75nm process technology.

Key Specifications

Memory Type FLASH – NOR (Non-Volatile)
Memory Size 64Mbit (8M x 8)
Interface SPI – Quad I/O, QPI
Clock Frequency 133 MHz (max)
Voltage Supply 1.65V ~ 2.0V (1.8V nominal)
Operating Temperature -40°C ~ 85°C
Package 8-SOP (200mil)
Process Technology 75nm
Page Size 256 bytes
Endurance 100,000 cycles

Features

  • 1.8V single supply operation: 1.65V to 2.0V
  • MXSMIO™: Single I/O, Dual I/O, Quad I/O support
  • Quad Peripheral Interface (QPI) mode
  • 133MHz max clock frequency with Quad I/O
  • 75nm advanced process technology
  • Uniform 4KB sectors and 64KB blocks
  • Program/Erase Suspend and Resume
  • Burst Read capability
  • Advanced Sector Protection
  • 8K-bit Secured OTP (factory + customer)
  • Hardware Reset support
  • Unique ID feature
  • XIP (execute-in-place) support
  • SFDP compliant
  • RoHS compliant and halogen-free

Applications

  • 1.8V low-power embedded systems
  • Mobile and handheld devices
  • IoT and wearable electronics
  • Tablets and smartphones
  • Portable medical devices
  • Wireless communication modules
  • SSD and storage device firmware
  • Networking equipment with 1.8V rails

The MX25U6432FM2I02 is a 64Mbit 1.8V CMOS serial multi-I/O NOR Flash memory from Macronix’s MX25U series. Designed specifically for low-voltage systems, it operates from 1.65V to 2.0V with 1.8V nominal, making it ideal for mobile and battery-powered applications. The device features MXSMIO™ (Serial Multi I/O) technology supporting Single I/O, Dual I/O, and Quad I/O modes, along with QPI (Quad Peripheral Interface) mode for maximum throughput. Manufactured using Macronix’s 75nm process technology, it achieves clock frequencies up to 133MHz. The 64Mbit memory is organized as 8M x 8 bits with uniform 4KB sectors and 64KB blocks. Advanced features include Program/Erase Suspend/Resume, Burst Read with configurable wrap, Advanced Sector Protection with individual block and password protection, 8K-bit secured OTP memory, hardware reset, and unique ID. It supports XIP (execute-in-place) operation for direct code execution without shadow RAM. The 8-pin 200mil SOP package provides a standard compact form factor.

The MX25U6432F operates as a 1.8V multi-I/O serial NOR Flash memory optimized for low-voltage operation. In standard SPI mode, data transfer occurs via the SI/SO pins at SCLK rates up to 133MHz. In Quad I/O mode, all four data pins (SI/SO/WP/HOLD) are used for bidirectional data transfer, providing four times the throughput of single I/O mode. QPI mode extends this further by allowing commands and addresses to also be transferred on all four I/O pins, reducing instruction overhead and maximizing effective bandwidth. The device uses 24-bit addressing for the full 64Mbit capacity. Program operations support standard Page Program and Quad Page Program modes. Erase operations target 4KB sectors, 32KB/64KB blocks, or the entire chip. The internal state machine manages all program and erase operations automatically. Program/Erase Suspend/Resume allows temporarily pausing operations to access other memory regions. Advanced sector protection provides both individual sector/block protection and password-protected access control for enhanced security.

Pin Number Pin Name Type Description
1 CS# Input Chip Select, active low
2 SO/SIO1 I/O Serial Output / I/O1 in multi-I/QPI mode
3 WP#/SIO2 I/O Write Protect / I/O2 in quad/QPI mode
4 GND Ground Ground connection
5 SI/SIO0 I/O Serial Input / I/O0 in multi-I/QPI mode
6 SCLK Input Serial Clock input
7 HOLD#/RESET#/SIO3 I/O Hold/Reset / I/O3 in quad/QPI mode
8 VCC Power Power supply 1.65V-2.0V (1.8V nominal)
  • Low-power 1.8V embedded systems
  • Mobile phones and tablets
  • Wearable technology and smart watches
  • Portable medical diagnostic equipment
  • Wireless modems and RF modules
  • SSD controller firmware storage
  • Enterprise networking equipment
  • IoT edge devices with low voltage design
Manufacturer Part Number Description
Macronix MX25U6435FZNI02 64Mbit 1.8V Flash, 8-WSON package
Winbond W25Q64JWSSIQ 64Mbit 1.8V SPI Flash, Quad I/O, 133MHz
Micron MT25QU64ABB1EW9-0AAT 64Mbit 1.8V SPI Flash, Quad I/O, 133MHz
GigaDevice GD25LQ64CTIG 64Mbit 1.8V SPI Flash, Quad I/O, 120MHz
