MX29GL256FHT2I-90

256Mbit Parallel NOR Flash, Uniform Sectors, 90ns, 2.7-3.6V, 56-TSOP

4567

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

MX29GL256FHT2I-90

Package：

56-TSOP

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

MSP430F5304IRGZR

MS9282-1

OP2177ARMZ

NJM2068M

NCF3320EHN

NC7SZ126M5X

MT8870DSR1

MCP6S26-I

Description

Product Overview

The MX29GL256FHT2I-90 is a 256Mbit parallel NOR Flash memory from Macronix, part of the GL series featuring uniform sector architecture. It supports both x8 and x16 operation via BYTE# pin, with 90ns access time at 3.0V-3.6V supply. The device comes in a 56-TSOP package, operates over industrial temperature range, and features 256 uniform 128KB sectors. Advanced features include page read buffer, write buffer program, advanced sector protection (Solid Protection and Password Protection), and Vcc I/O for flexible I/O voltage.

Key Specifications

Memory Type FLASH – NOR (Non-Volatile)
Memory Size 256Mbit (32M x 8 / 16M x 16)
Interface Parallel (Asynchronous)
Access Time 90 ns
Voltage Supply 2.7V ~ 3.6V
Operating Temperature -40°C ~ 85°C
Package 56-TSOP
Architecture Uniform sectors: 256 x 128KB
Page Read Buffer 16 bytes / 8 words
Endurance 100,000 cycles

Features

  • 256Mbit density with uniform 128KB sector architecture
  • Byte/Word mode switchable via BYTE# pin
  • Fast access time: 90ns at 3.0V-3.6V
  • Page read time: 25ns (synchronous burst read)
  • Fast program time: 10us/word typical
  • Fast erase time: 0.5s/sector typical
  • 16-byte/8-word page read buffer
  • 64-byte/32-word write buffer
  • Advanced sector protection: Solid + Password
  • Extra 128-word security sector
  • Vcc I/O support (independent I/O voltage)
  • Hardware write protection
  • Software data protection
  • JEDEC standard compatible
  • Deep power-down mode
  • RoHS compliant

Applications

  • High-density code storage for embedded systems
  • Industrial control and automation
  • Automotive electronics
  • Networking and telecom equipment
  • Set-top boxes and digital TVs
  • Medical devices
  • Aerospace and defense systems
  • Data storage and server systems

The MX29GL256FHT2I-90 is a 256Mbit 3V supply parallel NOR Flash memory from Macronix’s MX29GL series. It features uniform sector architecture with 256 identical 128KB sectors, providing maximum flexibility for memory management and wear-leveling algorithms. The device supports both x8 and x16 data bus widths, configurable via the BYTE# pin. With 90ns access time at full voltage and page access time of 25ns, it delivers high read performance for code execution and data access. Advanced features include a 64-byte write buffer for fast programming, advanced sector protection with both solid and password-based protection schemes, and an additional 128-word security sector for unique device identification or secure key storage. The device also supports Vcc I/O for independent I/O buffer supply voltage, enabling interfacing with systems at different voltage levels. The 56-pin TSOP package provides a standard form factor for high-density parallel flash applications. It is suitable for demanding applications requiring high reliability and extended temperature operation.

The MX29GL256F operates as an asynchronous parallel NOR Flash memory. In read mode, when CE# and OE# are low and WE# is high, the device outputs data from the memory location specified by the address inputs. The access time of 90ns is the time from address stability to valid data output. The page read buffer allows faster sequential reads by prefetching a page of data into an internal buffer. For program operations, the device accepts commands via the command register interface, with programming performed either word-by-word or using the write buffer for faster multi-byte programming. Erase operations target individual sectors (128KB each) using uniform sector architecture. An internal state machine automatically manages all program and erase operations, with status reported via Data# Polling, Toggle Bit, and RY/BY# pin. Advanced sector protection allows sectors to be locked with either solid protection (permanent or until next reset) or password protection (requires 64-bit password to unlock). The BYTE# pin controls whether the device operates in x8 or x16 mode, with Q15/A-1 serving as the LSB address in byte mode.

Pin Type Count Description
A0-A23 24 Address inputs for 24-bit memory addressing
DQ0-DQ14 15 Data input/output lines
DQ15/A-1 1 DQ15 in word mode, A-1 address in byte mode
CE# 1 Chip Enable, active low
OE# 1 Output Enable, active low
WE# 1 Write Enable, active low
BYTE# 1 Byte/Word mode select (low=byte, high=word)
RY/BY# 1 Ready/Busy status output (open drain)
RESET# 1 Hardware Reset, active low
WP#/ACC 1 Write Protect / Accelerated Program input
VCC 2 Core power supply 2.7V-3.6V
VCCQ 1 I/O buffer power supply
GND 2+ Ground connections
NC Remaining No internal connections
  • High-density embedded system code storage
  • Industrial PLC and automation controllers
  • Automotive ADAS and infotainment
  • Telecommunications infrastructure
  • Cable/DSL modems and set-top boxes
  • Medical imaging and diagnostic equipment
  • Aerospace avionics systems
  • Enterprise storage and server BIOS
