5-1775443-3

3-pos 1.5mm vertical HPI header, fully shrouded, SMD, 3A, 250V, -55 to 105C

5215

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

5-1775443-3

Package：

SMD Header (6.0 x 6.0 x 5.0 mm)

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

C1206C226Z9VAC-TU

MA0805XR-106K-6R3ER

LQW18AN62NG00D

CC0603JRNPO9BN681

CC0603KRX7R7BB471

CC0603KRX7R9BB471

C3225X7T2W224K200AA

CC0603KRX7R8BB224

Description

Product Overview

The 5-1775443-3 from TE Connectivity is a 3-position vertical PCB mount header from the HPI (High Performance Interconnect) series with a 1.5 mm centerline. Fully shrouded with tin-plated brass contacts rated at 3 A, it provides surface-mount wire-to-board connectivity for signal applications in industrial and consumer electronics.

Key Specifications

Number of Positions 3
Centerline (Pitch) 1.5 mm [0.059 in]
PCB Mount Orientation Vertical
Header Type Fully Shrouded
Termination Method Surface Mount
Operating Voltage 250 VDC / 250 VAC
Contact Current Rating 3 A
Operating Temperature -55 to 105 degC
Package SMD Header (6.0 x 6.0 x 5.0 mm)

Features

  • HPI series 1.5 mm pitch interconnect system
  • Fully shrouded header for contact protection
  • Polarization for mating alignment
  • Brass contacts with 2.54 um bright tin plating
  • Natural color thermoplastic housing, UL94 V-0
  • Surface-mount termination with 1.55 mm tail length

Applications

  • Industrial signal wire-to-board connections
  • Consumer electronics internal board-to-board
  • Telecommunications equipment signal routing
  • Medical device internal interconnects
  • Automotive signal header interfaces

The 5-1775443-3 from TE Connectivity is a 3-position vertical PCB mount header from the HPI (High Performance Interconnect) series. It features a 1.5 mm centerline pitch with fully shrouded header design that protects contacts from damage and ensures correct mating orientation. The brass contacts are tin-plated with 2.54 um thickness and rated at 3 A per contact. The surface-mount termination with 1.55 mm tail length is compatible with standard reflow soldering processes. The thermoplastic housing meets UL94 V-0 flammability rating and the device operates from -55 to 105 degC.

The 5-1775443-3 operates as a wire-to-board interconnect header. The fully shrouded housing surrounds the male pin contacts on all four sides, providing physical protection and ensuring that the mating receptacle can only be inserted in the correct orientation through the polarization features. The 1.5 mm pitch allows for compact board layout while maintaining 250 V voltage rating and 3 A current capacity per contact. The surface-mount solder tails provide reliable PCB attachment through reflow soldering.

Pin Name Type Function
1 Contact 1 Contact Signal pin 1
2 Contact 2 Contact Signal pin 2
3 Contact 3 Contact Signal pin 3
  • Industrial control signal wire-to-board interfaces
  • Consumer electronics internal board connections
  • Telecom equipment low-profile signal routing
  • Medical device compact interconnect headers
  • Automotive signal distribution board headers
Manufacturer Part Number Package Notes
TE Connectivity 5-1775443-1 SMD 2-position variant
TE Connectivity 5-1775443-5 SMD 5-position variant
Molex 53261-0371 SMD 1.5mm pitch header, 3-pos
JST S3B-ZR-SM4A-TF SMD 1.5mm JST ZR equivalent
Hirose FX10C-30S-0.5SV SMD 0.5mm alternative
