Product Overview
The GJM1555C1H1R1BB01D is a high-Q chip multilayer ceramic capacitor from Murata’s GJM series. It features 1.1pF capacitance in a 0402 (1005 Metric) package with 50V DC voltage rating. The C0G (NP0) dielectric provides excellent temperature stability with 0±30 ppm/°C temperature coefficient, and the tight ±0.1pF tolerance makes it ideal for precision RF applications.
The GJM series is Murata’s high-Q (low loss) MLCC line optimized for high-frequency circuits. The ‘1555’ indicates 1.0 × 0.5 × 0.5mm dimensions, ‘1H’ denotes 50V rating, ‘1R1’ means 1.1pF, ‘B’ specifies ±0.1pF tolerance, and ‘B01’ is the individual specification control code. The ‘D’ suffix indicates φ180mm paper tape packaging with 10,000 pieces per reel.
Key Specifications
| Type | High-Q Chip Multilayer Ceramic Capacitor (MLCC) |
| Series | GJM (High-Q Type) |
| Package / Case | 0402 / 1005M (1.0 × 0.5 × 0.5 mm) |
| Capacitance | 1.1 pF (1R1 = 1.1 pF) |
| Rated Voltage | 50 V DC |
| Dielectric Type | C0G (NP0) — Class I Ceramic |
| Tolerance | ±0.1 pF (B) |
| Temperature Coefficient | 0 ± 30 ppm/°C |
| Temperature Range | -55°C ~ +125°C |
| Quality Factor (Q) | High Q (low ESR, RF optimized) |
| Mount Type | Surface Mount (SMD) — reflow only |
| Termination | Nickel barrier + Matte tin (lead-free) |
| Packaging | φ180mm paper tape, 10000pcs/reel (D suffix) |
| Weight | ~1.6 mg per piece |
| RoHS | Compliant |
| ESR | Very low at RF frequencies |
Features
- 1.1pF tight tolerance ±0.1pF
- C0G/NP0 Class I dielectric — ultra-stable
- 50V DC voltage rating
- High Q factor / low ESR for RF applications
- 0402 (1005M) compact package
- No DC bias effect (Class I ceramic)
- No capacitance aging drift
- ±30 ppm/°C temperature coefficient
- Suitable for reflow soldering only
- RoHS compliant / lead-free
- Murata GJM high-Q series quality
Applications
- RF impedance matching networks
- VCO and oscillator resonant circuits
- High-frequency filters (LC filters)
- RF front-end circuits
- Wireless communication modules
- Bluetooth, Wi-Fi, cellular transceivers
- Timing and frequency control circuits
- Low-loss signal coupling and bypass
