IR2101STRPBF

Infineon IR2101STRPBF high/low side gate driver, 600V, 130mA/270mA, SOIC-8

12650

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

IR2101STRPBF

Package：

SOIC-8

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

OC5A2B00

NCV887103D1R2G

NAE12S17-A

MIC4428YM

MIC2951-03BN

LTM4673Y

LTC3780IG

LTC3112EFE

Description

Product Overview

The IR2101STRPBF is a high-voltage, high-speed power MOSFET and IGBT driver from Infineon Technologies. This half-bridge driver features independent high-side and low-side referenced output channels with 600V floating capability, making it ideal for driving N-channel power devices in half-bridge and full-bridge topologies.

Key Specifications

Manufacturer Infineon Technologies
Device Type High-Side/Low-Side Gate Driver
V_OFFSET 600 V (max)
Output Current (Source/Sink) 130 mA / 270 mA (typ)
Supply Voltage Range 10 V to 20 V
UVLO Threshold (VCC) 8.6 V (on) / 8.2 V (off)
Propagation Delay (ton/toff) 620 ns / 220 ns (typ)
Dead Time Internal
Input Logic Compatibility CMOS / LSTTL
Package SOIC-8
Operating Temperature -40°C to +125°C

Features

  • Floating channel designed for bootstrap operation
  • Fully operational up to +600V
  • dV/dt immune, negative transient tolerant
  • Gate drive supply range: 10V to 20V
  • Undervoltage lockout
  • CMOS Schmitt-triggered inputs
  • Outputs in phase with inputs
  • Internal dead time for shoot-through protection
  • RoHS compliant, SOIC-8 package

Applications

  • AC motor drives
  • Switch-mode power supplies
  • Half-bridge and full-bridge converters
  • UPS systems
  • Welding equipment
  • LED drivers
  • Class D audio amplifiers
  • Industrial power supplies

The IR2101STRPBF is a high-voltage, high-speed power MOSFET and IGBT driver with independent high-side and low-side referenced output channels. Based on Infineon’s proprietary HVIC and latch-immune CMOS technologies, this device provides rugged monolithic construction with excellent noise immunity. The floating high-side channel, designed for bootstrap operation, is fully functional up to 600V offset voltage. The IR2101S accepts standard CMOS or LSTTL logic inputs and provides totem-pole output drive with built-in dead time to prevent shoot-through. With its compact SOIC-8 package and comprehensive feature set, the IR2101S is an excellent choice for cost-sensitive half-bridge and full-bridge power converter designs.

The IR2101STRPBF uses high-voltage level-shifting technology to transfer control signals from the low-voltage logic side to the high-voltage floating channel. The high-side driver is powered via a bootstrap capacitor that charges from the VCC supply when the low-side switch is on. The level-shift circuitry uses a high-voltage DMOS process to transmit the input logic state across the high-voltage barrier with minimal propagation delay. Internal dead time circuitry ensures there is a gap between turning off one channel and turning on the other, preventing shoot-through current in the power stage. The CMOS Schmitt-trigger inputs provide noise immunity and compatibility with 3.3V and 5V logic levels.

Pin Number Pin Name Function
1 LO Low-Side Gate Drive Output
2 VCC Low-Side Power Supply (10-20V)
3 HIN High-Side Input (Logic)
4 LIN Low-Side Input (Logic)
5 COM Common / Ground
6 VS High-Side Floating Return
7 HO High-Side Gate Drive Output
8 VB High-Side Floating Supply (Bootstrap)
  • AC induction and BLDC motor drives
  • Switch-mode power supplies (SMPS)
  • Half-bridge and full-bridge DC-DC converters
  • Uninterruptible power supplies (UPS)
  • Welding power supplies
  • LED driver circuits
  • Class D audio power amplifiers
  • Industrial power converters
Model Manufacturer Description
IR2104STRPBF Infineon Single input, 600V half-bridge driver
IR2101PBF Infineon DIP-8 through-hole version
TC4427 Microchip Alternative dual low-side driver
