LB1836

4-Channel Darlington Driver Array, 500mA/ch, 24V, SOP-24

5000

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

LB1836

Package：

SOP-24

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

MSP430F5304IRGZR

MS9282-1

OP2177ARMZ

NJM2068M

NCF3320EHN

NC7SZ126M5X

MT8870DSR1

MCP6S26-I

Description

Product Overview

The LB1836 is a 4-channel Darlington transistor array from ON Semiconductor (formerly Sanyo). Each channel can sink up to 500mA with 24V output rating. Built-in flyback diodes for inductive load driving. 24-pin SOP package.

Key Specifications

Type 4-Channel Darlington Array
Channels 4
Voltage 24V max
Current 500mA per channel
Flyback Diodes Built-in
Package 24-pin SOP

Features

  • 4 independent Darlington channels
  • 500mA per channel output
  • 24V output rating
  • Built-in flyback diodes
  • TTL/CMOS compatible inputs
  • 24-pin SOP package

Applications

  • DC motor driving
  • Relay driving
  • LED driving
  • Solenoid driving
  • Home appliances
  • Industrial control

The LB1836 is a 4-channel Darlington transistor array from ON Semiconductor (formerly Sanyo). Each channel can sink up to 500mA with 24V output rating. Built-in flyback diodes for inductive load driving. 24-pin SOP package.

Four independent NPN Darlington pairs providing high current gain. Inputs are TTL/CMOS compatible. Built-in flyback diodes clamp inductive kickback.

Pin Name Description
IN1-IN4 Inputs 4 channel inputs (high active)
OUT1-OUT4 Outputs 4 open-collector outputs
COM Common Flyback diode common
VCC Logic Supply Logic power
GND Ground Ground
  • DC motor driving
  • Relay driving
  • LED driving
  • Solenoid driving
  • Home appliances
  • Industrial control
Manufacturer Part Number Description
TI ULN2003A 7-channel Darlington array
Toshiba TD62083F 8-channel driver
ON Semi MC1413 7-channel Darlington
Recommend Parts
