LM5007

High-voltage buck regulator, 7-75V input, 500mA, COT control, 8-MSOP, programmable frequency/limit

8122

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

LM5007

Package：

8-MSOP

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

MSP430F5304IRGZR

MS9282-1

OP2177ARMZ

NJM2068M

NCF3320EHN

NC7SZ126M5X

MT8870DSR1

MCP6S26-I

Description

Product Overview

The LM5007 is a high-voltage step-down (buck) switching regulator designed for high-input-voltage applications requiring efficient DC-DC conversion. Manufactured by Texas Instruments, this monolithic regulator integrates a high-voltage power MOSFET capable of operating from input voltages up to 75V. The constant on-time (COT) control architecture provides excellent transient response and simplifies compensation design. The device features programmable switching frequency, current limit, and soft-start, making it highly versatile for a wide range of high-voltage power conversion applications.

Key Specifications

Type High-Voltage Step-Down (Buck) Regulator
Input Voltage Range 7V ~ 75V (80V absolute max)
Output Voltage Range 2.5V ~ VIN (adjustable)
Switch Current Limit 500 mA (minimum)
Switching Frequency 100kHz ~ 1MHz (programmable)
Integrated Switch 75V, N-channel MOSFET
Quiescent Current 1.6 mA typical (no load)
Control Topology Constant On-Time (COT)
Enable/Shutdown Yes (EN pin, 1µA shutdown)
Soft-Start Programmable (external capacitor)
Package 8-Pin MSOP / SOP-8
Operating Temperature -40°C ~ +125°C

Features

  • Wide input voltage: 7V to 75V
  • Integrated 75V power MOSFET
  • Constant on-time (COT) control mode
  • No compensation network required
  • Excellent transient response
  • Programmable switching frequency
  • Programmable current limit
  • Programmable soft-start
  • 1µA shutdown current
  • Internal bootstrap diode
  • Thermal shutdown protection
  • RoHS compliant and halogen-free

Applications

  • 48V telecom and datacom power systems
  • Industrial 24V/48V bus converters
  • Automotive battery regulation
  • High-voltage LDO replacement
  • LED driver applications
  • Power over Ethernet (PoE) powered devices
  • HVAC and building automation
  • Battery-powered high-voltage systems

The LM5007 is a monolithic high-voltage step-down switching regulator from Texas Instruments designed to efficiently step down wide input voltages in the 7V to 75V range. The device integrates a 75V N-channel MOSFET switch and operates using a constant on-time (COT) control architecture that provides excellent line and load transient response with minimal external components. Unlike fixed-frequency PWM regulators that require complex compensation networks, the COT architecture inherently stabilizes with output capacitor ESR, simplifying design and reducing component count. The LM5007 provides a minimum 500mA output current capability with programmable switching frequency from 100kHz to 1MHz via a single resistor. The current limit threshold is also programmable using an external resistor, allowing designers to optimize for efficiency or current handling. The device features programmable soft-start to manage inrush current during startup, and an enable pin with low 1µA shutdown current for power management. Additional protection features include thermal shutdown, input undervoltage lockout, and cycle-by-cycle current limiting. Packaged in an 8-pin MSOP (miniature small outline package), the LM5007 is ideal for space-constrained high-voltage applications including 48V telecom systems, industrial bus converters, automotive electronics, and LED drivers where high efficiency and reliable high-voltage operation are essential.

The LM5007 operates as a high-voltage step-down (buck) DC-DC converter using constant on-time (COT) control architecture. In a buck converter, the output voltage is regulated by switching the input voltage on and off at a controlled duty cycle, then filtering the resulting square wave with an LC low-pass filter. The output voltage is VOUT = VIN × D, where D is the duty cycle (ton / Tsw). In COT control mode, the on-time of the power switch is held approximately constant, while the off-time varies to regulate the output voltage. When the output voltage falls below the regulation threshold (FB pin below 2.5V reference), the high-side MOSFET turns on for a fixed duration (ton). The on-time is inversely proportional to VIN (ton ≈ 1/VIN), which maintains an approximately constant switching frequency across input voltage variations. When the on-time expires, the switch turns off and the inductor current freewheels through the catch diode (or synchronous rectifier). The switch remains off until the output voltage again falls below the threshold, at which point the cycle repeats. This ripple-based control provides inherently fast transient response because the regulator responds immediately to output voltage changes without waiting for a clock edge. The LM5007 integrates the high-side 75V MOSFET switch and bootstrap diode, eliminating the need for external power components for the switch itself. The current limit comparator monitors the switch current cycle-by-cycle, terminating the on-time early if the current exceeds the programmed threshold. The soft-start feature gradually increases the effective regulation voltage during startup to control inrush current. The EN pin allows external on/off control, with only 1µA supply current in shutdown mode.

Pin Number Pin Name Type Description
1 VIN Power Input voltage supply (7V-75V)
2 EN Input Enable pin (UVLO and shutdown control)
3 RT Input Switching frequency programming resistor
4 SS Input Soft-start capacitor connection
5 FB Input Feedback voltage input (2.5V reference)
6 RES Input Current limit programming resistor
7 GND Power Ground (power and signal)
8 BST Output Bootstrap pin (internal bootstrap diode to VIN)
EP SW Output Switch node (exposed pad), connects to inductor and catch diode
  • 48V telecom power supply step-down
  • Industrial 24V/36V bus regulators
  • Automotive battery (12V/24V) regulation
  • High-voltage LDO replacement for efficiency
  • LED constant-current drivers
  • PoE (Power over Ethernet) PD converters
  • Building automation and HVAC control
  • High-voltage battery-powered equipment
