MC145162P

PLL Frequency Synthesizer, 150MHz, CMOS, DIP-20

5000

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

MC145162P

Package：

DIP-20

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

MSP430F5304IRGZR

MS9282-1

OP2177ARMZ

NJM2068M

NCF3320EHN

NC7SZ126M5X

MT8870DSR1

MCP6S26-I

Description

Product Overview

The MC145162P is a CMOS PLL frequency synthesizer from ON Semiconductor (formerly Motorola). Includes reference oscillator, phase/frequency detector, 14-bit R counter, and 17-bit N counter. RF input up to 150MHz. 20-pin DIP package.

Key Specifications

Type PLL Frequency Synthesizer
RF Input Up to 150MHz
R Counter 14-bit (1-16383)
N Counter 17-bit (3-131071)
Voltage 3V ~ 9V CMOS
Lock Detect Built-in
Package 20-pin DIP

Features

  • Complete PLL synthesizer on chip
  • Built-in reference oscillator
  • 14-bit R counter, 17-bit N counter
  • Phase/frequency detector
  • Lock detect output
  • Wide 3-9V supply range
  • Low power CMOS
  • 20-pin DIP

Applications

  • RF communication equipment
  • Wireless transceivers
  • Frequency synthesizers
  • Clock generation
  • Test instruments
  • Amateur radio

The MC145162P is a CMOS PLL frequency synthesizer from ON Semiconductor (formerly Motorola). Includes reference oscillator, phase/frequency detector, 14-bit R counter, and 17-bit N counter. RF input up to 150MHz. 20-pin DIP package.

PLL frequency synthesizer with programmable R and N counters. Phase/frequency detector generates error signal for VCO control. Lock detect output indicates lock condition.

Pin Name Description
OSC_IN/OUT Oscillator Reference crystal connection
Fin RF Input VCO frequency input
PDout Phase Detector Phase error output
LD Lock Detect Lock status output
R0-R8 R Counter Data Reference divider data
N0-N10 N Counter Data Main divider data
STROBE Strobe Data latch strobe
