MP9942GJ-Z

Synchronous Buck Converter, 4-36V In, 2A Out, 410kHz, Power Good, TSOT-23-8

15005

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

MP9942GJ-Z

Package：

TSOT-23-8

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

MSP430F5304IRGZR

MS9282-1

OP2177ARMZ

NJM2068M

NCF3320EHN

NC7SZ126M5X

MT8870DSR1

MCP6S26-I

Description

Product Overview

The MP9942GJ-Z is a high-efficiency synchronous step-down (buck) DC-DC converter from Monolithic Power Systems (MPS). It operates over a wide 4V to 36V input voltage range and delivers up to 2A continuous output current with excellent load and line regulation. The device features 410kHz switching frequency, internal soft-start, power good indicator, over-current protection, and thermal shutdown. Available in a space-saving 8-pin TSOT-23 package, it is ideal for compact power supply designs.

Key Specifications

Type Synchronous Step-Down (Buck) Converter
Input Voltage 4V ~ 36V (36V transient)
Output Current 2A (continuous)
Output Voltage 0.8V ~ 32.4V (adjustable)
Switching Frequency 410kHz (fixed)
Sync Range 200kHz ~ 2.2MHz external clock
Top MOSFET Rds(on) 90mΩ
Bottom MOSFET Rds(on) 55mΩ
Operating Temp -40°C ~ 125°C (TJ)
Package TSOT-23-8

Features

  • Wide 4V to 36V continuous operating input range
  • 36V input transient withstand voltage
  • 90mΩ / 55mΩ low Rds(on) internal power MOSFETs
  • High-efficiency synchronous mode operation
  • 410kHz fixed switching frequency
  • Synchronizable from 200kHz to 2.2MHz external clock
  • High duty cycle for automotive cold-crank
  • Internal power-save mode for light load
  • Internal soft-start function
  • Power good indicator (PG)
  • Over-current protection with hiccup mode
  • Thermal shutdown protection
  • Output adjustable from 0.8V
  • Current mode control for fast transient
  • RoHS compliant (RoHS3)

Applications

  • Industrial power supplies
  • Automotive electronics (cold-crank)
  • Distributed power systems
  • Point-of-load converters
  • Networking and telecom equipment
  • Consumer electronics
  • Set-top boxes and TVs
  • Battery-powered devices

The MP9942GJ-Z is a high-frequency, synchronous, rectified, step-down switch-mode converter with built-in power MOSFETs from Monolithic Power Systems (MPS). It offers a very compact solution to achieve 2A continuous output current with excellent load and line regulation over a wide 4V to 36V input supply range. The MP9942 operates in synchronous mode for higher efficiency across the full output current range. Current-mode control provides fast transient response and eases loop stabilization. The device integrates 90mΩ high-side and 55mΩ low-side power MOSFETs for high efficiency. Key features include internal soft-start to limit inrush current, power good (PG) indicator for power sequencing, over-current protection with hiccup mode recovery, and thermal shutdown. The switching frequency is fixed at 410kHz and can be synchronized to an external clock from 200kHz to 2.2MHz via the EN/SYNC pin. The output voltage is adjustable from 0.8V up to 32.4V via external resistors. The MP9942 is available in an 8-pin TSOT-23 package and is suitable for a wide range of applications including industrial, automotive, consumer, and networking power supplies.

The MP9942 operates as a peak-current-mode controlled synchronous buck converter. Each switching cycle begins with the internal clock turning on the high-side (HS) MOSFET, allowing current to flow from VIN through the inductor to the output capacitor and load. The inductor current ramps up, and when it reaches the level set by the error amplifier output (COMP), the HS MOSFET turns off and the low-side (LS) MOSFET turns on. During this phase, the inductor current ramps down as it flows through the LS MOSFET. The LS MOSFET remains on until the next clock cycle. The output voltage is sensed via the FB pin and compared to an internal 0.8V reference by the error amplifier. The error amplifier output controls the peak inductor current, providing voltage regulation. For light loads, the device enters AAM (Advanced Asynchronous Modulation) power-save mode to maintain high efficiency. Synchronization to an external clock is possible via the EN/SYNC pin. Internal soft-start gradually increases the output voltage during startup to limit inrush current. Protection features include cycle-by-cycle current limit with hiccup recovery for short circuits and thermal shutdown for over-temperature protection.

Pin Number Pin Name Type Description
1 EN/SYNC Input Enable / External clock synchronization
2 BST Bootstrap Bootstrap for high-side gate driver
3 SW Output Switch node output (connect to inductor)
4 PGND Ground Power ground
5 FB Input Feedback voltage input
6 PG Output Power good indicator (open drain)
7 VCC Output Internal regulator output (bypass with 0.1uF)
8 VIN Power Input voltage supply (4V-36V)
  • Industrial control power supplies
  • Automotive infotainment and body electronics
  • Distributed power architecture systems
  • Point-of-load DC-DC converters
  • Network routers and telecom equipment
  • Consumer electronics and appliances
  • Set-top boxes and TV power supplies
  • Wide-input battery-powered systems
