OP6180-1-IBAG

Precision operational amplifier, 10MHz GBW, 2.7-12V supply, SOT-23-5 package

8750

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

OP6180-1-IBAG

Package：

IBAG / SOT-23-5 (2.9 x 1.6 x 1.1 mm)

Brand：
Product Categories：

Quality Commitment

Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

RM5532AL

RDA5856TE

RA80H1415M1

R5F109BCK

R2A20178NP

QMC5883L

PS2805C-1-F3-A

PIC32MZ1024ECG100-I

Description

Product Overview

The OP6180-1-IBAG is a high-performance operational amplifier designed for precision analog signal processing applications. Manufactured with advanced CMOS technology, this device offers excellent DC accuracy and AC performance characteristics, making it suitable for instrumentation, data acquisition, and industrial control systems. The IBAG package variant provides a compact surface-mount solution optimized for automated PCB assembly and high-volume production environments.

Key Specifications

Number of Channels 1 (Single)
Supply Voltage Range 2.7V to 12V
Input Offset Voltage 150 μV (max)
Gain Bandwidth Product 10 MHz
Slew Rate 6 V/μs
Supply Current 850 μA per channel
Input Bias Current 1 pA (typ)
Operating Temperature -40°C to +125°C
Package Type IBAG (SOT-23-5)

Features

  • Low input offset voltage for precision applications
  • Wide supply voltage range: 2.7V to 12V
  • 10 MHz gain bandwidth product
  • Low input bias current (pA level)
  • Low power consumption: 850 μA per channel
  • Unity-gain stable configuration
  • Extended industrial temperature range
  • Compact SOT-23-5 surface-mount package

Applications

  • Precision data acquisition systems
  • Industrial process control
  • Instrumentation amplifiers
  • Active filters and signal conditioning
  • Sensor signal amplification
  • Battery-powered portable equipment

The OP6180-1-IBAG is a precision operational amplifier featuring exceptional DC accuracy and AC performance. Built on advanced CMOS process technology, this single-channel amplifier delivers 10 MHz gain bandwidth with only 850 μA supply current, achieving an optimal balance between performance and power efficiency. The device offers low input offset voltage (150 μV max) and picoamp-level input bias currents, making it ideal for high-impedance sensor interfaces and precision signal conditioning circuits. The SOT-23-5 package enables space-saving designs in portable and compact electronic systems. With an operating temperature range of -40°C to +125°C, the OP6180-1-IBAG is well-suited for industrial and automotive applications requiring reliable performance across extreme environmental conditions.

The OP6180-1-IBAG operational amplifier operates on the classic differential amplifier architecture with multiple gain stages. The input stage employs a differential pair with current mirror load, providing high common-mode rejection and low input offset. The intermediate gain stage provides additional voltage amplification via a folded-cascode structure, enhancing both gain and bandwidth performance. The output stage features a class AB push-pull configuration capable of driving low-impedance loads with minimal crossover distortion. Internal frequency compensation ensures unity-gain stability, allowing the device to be used in follower configurations without external compensation components. The device maintains stable operation over a wide supply voltage range from 2.7V to 12V, with rail-to-rail output swing capability that maximizes dynamic range in single-supply applications.

Pin Name Type Function
1 OUT Output Amplifier output pin
2 IN- Input Inverting input terminal
3 IN+ Input Non-inverting input terminal
4 V- Power Negative supply voltage (GND in single-supply)
5 V+ Power Positive supply voltage
  • Precision data acquisition and measurement systems
  • Industrial process control and monitoring
  • Sensor signal amplification and conditioning
  • Active filter design and frequency selection
  • Battery-powered portable instruments
  • Medical diagnostic equipment
Manufacturer Part Number Package Notes
Texas Instruments OPA333 SOT-23-5 Low-power precision op-amp, 1.8V supply
Microchip MCP6001 SOT-23-5 General-purpose, 1MHz, low cost
Analog Devices AD8605 SOT-23-5 Precision CMOS, rail-to-rail I/O
onsemi NCS20071 SOT-23-5 Low-power, 5.5MHz, RRIO
