OSC12A2B17

12MHz crystal oscillator module, ±20ppm, 3.3V, CMOS output, SMD 7x5mm package

10500

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

OSC12A2B17

Package：

SMD 7.0 x 5.0 mm (DIP-8 compatible footprint)

Brand：
Product Categories：

Quality Commitment

Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

STD25NF10T4

SQ4401EY-T1-GE3

SIHG20N50C-E3

SI2309CDS-T1-GE3

RNR55C

OSC5A2B04

OSC5A2B03

OC3SC25

Description

Product Overview

The OSC12A2B17 is a high-stability crystal oscillator module designed to provide precise clock timing for digital electronic systems. Featuring a frequency of 12 MHz with excellent temperature stability and low phase noise, this oscillator delivers reliable reference signals for microcontrollers, communication interfaces, and data acquisition circuits. The compact surface-mount package design is optimized for automated PCB assembly, making it suitable for high-volume consumer electronics, industrial control, and telecommunications applications.

Key Specifications

Nominal Frequency 12 MHz
Frequency Stability ±20 ppm over temperature
Supply Voltage 3.3V (2.4V to 3.6V)
Output Type CMOS / TTL compatible
Output Enable Active high / tri-state
Phase Noise -135 dBc/Hz @ 1 kHz offset
Operating Temperature -40°C to +85°C
Supply Current 10 mA (typ)
Package Type SMD 7.0 x 5.0 mm (DIP-8 footprint)
Aging ±3 ppm / year (max)

Features

  • Precision 12 MHz frequency output
  • ±20 ppm frequency stability over temperature
  • Wide supply voltage range: 2.4V to 3.6V
  • CMOS/TTL compatible output
  • Low phase noise and jitter performance
  • Output enable/tri-state function
  • Compact surface-mount package
  • RoHS compliant and lead-free

Applications

  • Microcontroller and processor clock sources
  • Communication interfaces (UART, SPI, I2C)
  • Networking and telecom equipment
  • Data acquisition and measurement systems
  • Consumer electronics devices
  • Industrial automation and control
  • Test and measurement instrumentation

The OSC12A2B17 is a fully integrated crystal oscillator (XO) module that provides a precise 12 MHz clock signal for digital electronic systems. This device combines a high-quality AT-cut quartz crystal resonator with a CMOS oscillator circuit in a compact surface-mount package, eliminating the need for external frequency-setting components and simplifying design integration. The oscillator delivers excellent frequency stability of ±20 ppm across the full operating temperature range of -40°C to +85°C, ensuring reliable timing performance in varying environmental conditions. With a supply voltage range of 2.4V to 3.6V, the OSC12A2B17 is compatible with standard 3.3V system designs and can also operate from lower voltage rails in battery-powered applications. The CMOS output provides fast rise and fall times with sufficient drive capability for clock distribution across multiple loads. The device features an output enable pin that allows the output to be tri-stated, enabling power management and system-level clock control functions. Long-term frequency aging is specified at ±3 ppm per year maximum, ensuring stable performance throughout the product lifecycle.

The OSC12A2B17 oscillator module operates on the principle of piezoelectric resonance in an AT-cut quartz crystal. The quartz crystal, when cut at a specific angle to the crystal lattice, vibrates at a precise mechanical frequency when electrically excited. This mechanical resonance is converted back into an electrical signal by the piezoelectric effect, providing an extremely stable frequency reference. The internal oscillator circuit uses a Pierce oscillator topology, which consists of an inverting amplifier with the crystal connected between its input and output, along with internal load capacitors that determine the exact oscillation frequency. The output of the oscillator is fed into a buffer amplifier stage, which isolates the resonator from the load and provides the drive strength needed to drive external circuit elements. A voltage regulator within the module ensures stable operation of the oscillator circuit despite variations in supply voltage, contributing to the device’s excellent power supply rejection performance. The output enable control logic allows the output buffer to be placed in a high-impedance state, which can reduce power consumption and enable clock distribution multiplexing in multi-source systems.

Pin Name Type Function
1 OE Input Output Enable (high = enable, low = tri-state)
2 GND Power Ground connection
3 OUT Output Clock signal output (CMOS/TTL)
4 VCC Power Positive supply voltage (3.3V nominal)
5-8 GND Power Additional ground pins (shielding)
  • Microcontroller and embedded processor clock generation
  • UART, SPI, I2C, and other serial communication interfaces
  • Networking and telecommunications equipment timing
  • Data acquisition and digital signal processing systems
  • Consumer electronics including set-top boxes and routers
  • Industrial automation and process control equipment
Manufacturer Part Number Package Notes
SiTime SiT8008 7x5mm SMD MEMS oscillator, 1-80MHz, ±25ppm
Abracon ASDMB-12.000MHZ 7x5mm SMD 12MHz crystal oscillator, ±20ppm
ECS ECS-120-20-4PX DIP-14 12MHz through-hole oscillator
TXC 7M-12.000MBA 7x5mm SMD 12MHz CMOS oscillator, ±50ppm
