STD25NF10T4

N-channel MDmesh power MOSFET, 100V VDS, 25A ID, 50mΩ RDS(on), DPAK, AEC-Q101 qualified

4641

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

STD25NF10T4

Package：

DPAK (TO-252)

Brand：
Product Categories：

Quality Commitment

Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

SQ4401EY-T1-GE3

SIHG20N50C-E3

SI2309CDS-T1-GE3

IRLZ44NPBF

IRLR3110ZPBF

IRLML0100TRPBF

IRLML0030TRPBF

IRLR2905TRPBF

Description

Product Overview

The STD25NF10T4 is an N-channel power MOSFET from STMicroelectronics, featuring a 100V drain-source voltage rating and 25A continuous drain current capability. Utilizing ST’s advanced MDmesh technology, this device offers extremely low on-resistance (RDS(on)) combined with low gate charge, providing an excellent figure of merit for high-efficiency switching applications. The T4 variant comes in the industry-standard DPAK (TO-252) surface mount package. Ideal for switching power supplies, DC-DC converters, motor control, and automotive applications.

Key Specifications

Manufacturer STMicroelectronics
Product Category N-Channel Power MOSFET
Technology MDmesh (strip layout)
Drain-Source Voltage (VDS) 100 V
Gate-Source Voltage (VGS) ±20 V
Continuous Drain Current (TC=25°C) 25 A
Continuous Drain Current (TC=100°C) 18 A
Pulsed Drain Current 80 A
RDS(on) @ VGS=10V 0.05Ω (50 mΩ) typ, 0.06Ω max
RDS(on) @ VGS=4.5V 0.065Ω (65 mΩ) typ
Gate-Source Threshold Voltage 2.0V (min), 4.0V (max)
Total Gate Charge (Qg) ≈ 35 nC (typ)
Input Capacitance (Ciss) ≈ 1000 pF (typ)
Diode Forward Voltage (VSD) ≈ 1.0 V (typ)
Power Dissipation (TC=25°C) 90 W
Operating Temperature Range -55°C to +175°C
Package DPAK (TO-252, SMD)
AEC-Q101 Qualified (automotive grade)

Features

  • N-channel 100V power MOSFET
  • Advanced MDmesh technology for ultra-low RDS(on)
  • Low RDS(on) x Qg figure of merit
  • Very low on-resistance: 50 mΩ typical
  • High current capability: 25A continuous
  • Fast switching with low gate charge
  • Logic-level gate drive compatible
  • 100% avalanche tested
  • Excellent dv/dt ruggedness
  • Fast body diode with low recovery charge
  • AEC-Q101 qualified (automotive grade)
  • RoHS compliant
  • Surface mount DPAK (TO-252) package
  • Wide operating temperature: -55°C to +175°C

Applications

  • Switch-mode power supplies (SMPS)
  • DC-DC converters
  • Automotive electronics
  • Motor control and drives
  • Load switching and power distribution
  • LED lighting drivers
  • Battery management systems
  • Synchronous rectification

The STD25NF10T4 is a high-performance N-channel enhancement-mode power MOSFET from STMicroelectronics, fabricated using their advanced MDmesh (strip layout) technology. This 100V device offers an outstanding combination of low on-resistance (RDS(on) = 50 mΩ typical at VGS=10V) and low gate charge, resulting in an excellent figure of merit that translates directly into higher efficiency in switching applications. With a 25A continuous drain current rating and 80A pulsed current capability, this MOSFET can handle significant power levels even in the compact DPAK surface mount package. The device is logic-level compatible, with a gate threshold as low as 2V, allowing direct driving from 5V or even 3.3V logic circuits. The body diode has fast recovery characteristics, which is beneficial for hard-switching topologies and synchronous rectification applications. AEC-Q101 qualification ensures automotive-grade reliability and quality. The DPAK (TO-252) surface mount package provides good thermal performance while minimizing PCB footprint. The STD25NF10T4 is widely used in switch-mode power supplies, DC-DC converters, automotive systems, motor drives, LED lighting, and battery management applications where high efficiency and reliable performance are essential.

The STD25NF10T4 is an N-channel enhancement-mode MOSFET utilizing STMicroelectronics’ MDmesh (strip mesh) technology, which features a novel drain structure with a deep P+ strip diffusion that reduces the specific on-resistance beyond conventional planar or trench MOSFET limits. When a positive voltage greater than the threshold voltage (typically 2-4V) is applied between gate and source, an N-type inversion channel forms in the P-body region beneath the gate oxide, allowing current to flow from drain to source. Since it is enhancement-mode, the device is normally off (non-conducting) when VGS = 0. The MDmesh architecture achieves very low specific on-resistance by optimizing the drift region resistivity through the deep P-pillar structure, enabling both high breakdown voltage and low conduction losses. The body diode (formed by the P-body/N-drift junction) can conduct in the reverse direction and has fast reverse recovery characteristics. The gate is insulated from the channel by a thin silicon dioxide layer, providing very high input impedance and negligible steady-state gate current. The device also features excellent avalanche energy capability and high dv/dt ruggedness for robust operation in demanding switching environments.

Pin Number Pin Name Description
1 Gate (G) Gate Terminal – Controls MOSFET conduction
2 Drain (D) Drain Terminal – connected to tab/heatsink
3 Source (S) Source Terminal
Tab Drain (D) Metal Tab – connected to Drain pin 2

Note: DPAK (TO-252) package. The tab is electrically connected to the drain and serves as a thermal path for heatsinking.

  • Switch-mode power supplies and DC-DC converters
  • Automotive power electronics (AEC-Q101 qualified)
  • Motor control and brushless DC drives
  • Load switching and power distribution
  • LED lighting driver circuits
  • Battery management and protection
  • Synchronous rectification applications
  • Telecom and server power systems
Model Manufacturer Description
IRF540N Infineon N-MOS, 100V, 33A, TO-220
FQPF10N60C onsemi N-MOS, 600V, 10A, TO-220F
IPD04N06LA Infineon OptiMOS, 60V, 40A, DPAK
FDD8896 onsemi N-MOS, 100V, 27A, D2PAK
STD70N03 STMicroelectronics N-MOS, 30V, 70A, DPAK
