OSC5A2B03

5MHz crystal oscillator, ±20ppm stability, 3.3V CMOS, SMD 7x5mm package

7800

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

OSC5A2B03

Package：

SMD 7.0 x 5.0 mm (DIP-8 compatible footprint)

Brand：
Product Categories：

Quality Commitment

Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

STD25NF10T4

SQ4401EY-T1-GE3

SIHG20N50C-E3

SI2309CDS-T1-GE3

RNR55C

OSC5A2B04

OSC12A2B17

OC3SC25

Description

Product Overview

The OSC5A2B03 is a 5 MHz precision crystal oscillator module providing a stable clock reference for digital and mixed-signal electronic systems. This oscillator combines a high-quality quartz crystal with integrated oscillator circuitry in a compact surface-mount package, delivering reliable timing performance with ±20 ppm frequency stability over temperature. Suitable for a wide range of applications including industrial control, automotive electronics, and telecommunications, the 5 MHz frequency provides an excellent balance between system timing resolution and power consumption.

Key Specifications

Nominal Frequency 5 MHz
Frequency Stability ±20 ppm over temperature
Supply Voltage 3.3V (2.4V to 3.6V)
Output Type CMOS compatible
Output Enable Active high / tri-state
Phase Noise -140 dBc/Hz @ 1 kHz offset
Operating Temperature -40°C to +85°C
Supply Current 8 mA (typ)
Package Type SMD 7.0 x 5.0 mm (DIP-8 footprint)
Aging ±3 ppm / year (max)

Features

  • 5 MHz precision clock output
  • ±20 ppm frequency stability over -40°C to +85°C
  • Low power consumption: 8 mA typical
  • Wide supply voltage: 2.4V to 3.6V
  • CMOS output with tri-state enable
  • Low phase noise and jitter
  • Compact SMD 7×5 mm package
  • RoHS compliant, lead-free construction

Applications

  • Industrial control and automation systems
  • Automotive electronics and infotainment
  • Microcontroller clock sources
  • Data communication interfaces
  • Smart grid and metering equipment
  • Medical devices and instrumentation
  • Security and surveillance systems

The OSC5A2B03 is a high-quality 5 MHz crystal oscillator module designed for applications requiring precise and reliable clock generation. This fully integrated device incorporates an AT-cut quartz crystal resonator paired with a CMOS oscillator circuit, all packaged in a standard 7.0 x 5.0 mm surface-mount form factor. The 5 MHz output frequency provides a versatile clock source suitable for driving microcontrollers, UARTs, and various digital peripherals while maintaining low power consumption. With frequency stability of ±20 ppm across the -40°C to +85°C operating temperature range, this oscillator ensures consistent timing performance in challenging environmental conditions. The CMOS output delivers strong drive capability with fast edge rates, enabling reliable clock distribution to multiple loads on the PCB. The OSC5A2B03 features an output enable pin that allows the clock output to be placed in a high-impedance state, supporting power management strategies and enabling easy integration into multi-clock domain systems. Long-term frequency stability is ensured with a maximum aging rate of ±3 ppm per year, making this oscillator suitable for products with extended service life requirements.

The OSC5A2B03 utilizes the piezoelectric properties of a precisely cut quartz crystal to generate its 5 MHz output frequency. The AT-cut crystal resonates at a fundamental frequency determined by its physical dimensions and crystallographic orientation. When an AC voltage is applied across the crystal’s electrodes, mechanical vibrations are induced through the inverse piezoelectric effect, and these vibrations in turn generate an electrical output at the resonant frequency through the direct piezoelectric effect. The internal oscillator circuitry employs a Pierce-gate architecture, using a single inverting CMOS amplifier with the crystal connected between input and output as the frequency-determining element. Internal load capacitors are matched to the crystal’s specified load capacitance to ensure accurate frequency output. The output buffer stage isolates the resonator from external loading effects and provides sufficient current drive for the CMOS output signal. An onboard voltage regulator provides a stable supply to the oscillator core, giving the device good power supply rejection and reducing sensitivity to supply voltage variations. The output enable function controls the output buffer state, allowing tri-stating for system-level clock management.

Pin Name Type Function
1 OE Input Output Enable: high = output enabled, low = tri-state
2 GND Power Ground reference pin
3 OUT Output 5 MHz clock signal output (CMOS levels)
4 VCC Power Positive power supply input (3.3V nominal)
5-8 GND Power Additional ground/shield pins
  • Industrial PLC and automation control systems
  • Automotive body electronics and infotainment modules
  • 8-bit and 16-bit microcontroller clock sources
  • Smart energy meters and grid monitoring equipment
  • Medical diagnostic and patient monitoring devices
  • Security systems and surveillance cameras
Manufacturer Part Number Package Notes
SiTime SiT8008AI-5M 7x5mm SMD 5MHz MEMS oscillator, ±25ppm
Abracon ASDMB-5.000MHZ 7x5mm SMD 5MHz crystal oscillator, ±20ppm
ECS ECS-50-20-4PX DIP-14 5MHz through-hole oscillator
Citizen CSX-750FBC5000M 7x5mm SMD 5MHz CMOS oscillator, ±50ppm
