π120U30

3-ch digital isolator, 3kVrms, 150Mbps, UVLO, -40~125°C, SOIC-16W, Si8630 alternative

9876

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

π120U30

Package：

SOIC-16W (10.3 x 7.5 mm)

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

LY62L12816ML-70LLI

LY62L51216ML-70LLI

CSS1604LS-LI

IS62WV102416GBLL-45TLI

W25Q40EWUXIE

IS62WV51216HBLL-45TLI

KLM8G1GETF-B041006

H26M41204HPR

Description

Product Overview

The π120U30 is a 3-channel digital isolator from 2Pai Semi (π Semi) with UVLO (Under Voltage Lock Out) feature. It provides 3kV rms isolation rating with up to 150 Mbps data rate per channel. The device is designed as a pin-compatible alternative to the Silicon Labs Si8630 and TI ISO7730 digital isolators, offering domestic (Chinese) supply chain security for industrial and automotive applications.

Key Specifications

Channels 3 (2 forward, 1 reverse)
Isolation Rating 3000 V rms
Data Rate Up to 150 Mbps
Propagation Delay ~10 ns typical
Supply Voltage 2.5V to 5.5V
UVLO Yes (both sides)
Operating Temp -40°C to +125°C
Package SOIC-16W
Part Status Active

Features

  • 3-channel digital isolator with UVLO
  • 3kV rms isolation rating
  • 150 Mbps data rate per channel
  • Pin-compatible with Si8630 / ISO7730
  • 2.5V to 5.5V wide supply range
    • UVLO on both Side 1 and Side 2
    • Low propagation delay (~10ns)
    • Automotive temperature support (-40°C to +125°C)
    • Domestic (Chinese) supply chain alternative

    Applications

    • Industrial communication interfaces (SPI, UART, I2C)
    • Motor drive and power inverter isolation
    • Automotive CAN/LIN bus isolation
    • BMS (Battery Management System) isolation

The π120U30 is a 3-channel digital isolator from 2Pai Semi with 3kV rms isolation rating and 150 Mbps data rate. It features UVLO on both sides, wide 2.5V to 5.5V supply range, and automotive-grade -40°C to +125°C temperature support. Pin-compatible with Silicon Labs Si8630 and TI ISO7730, it provides a domestic (Chinese) supply chain alternative for industrial and automotive isolation applications.

The π120U30 uses capacitive or transformer-based isolation to transmit digital signals across a galvanic barrier. Each channel consists of a modulator on the input side that encodes the digital state, an isolation barrier that transmits the encoded signal, and a demodulator on the output side that recovers the digital state. UVLO ensures the outputs default to a known state when either supply voltage drops below threshold, preventing erroneous data transmission during power-up/power-down transients. The 150 Mbps data rate supports high-speed SPI, UART, and other communication protocols.

Pin Name Side Function
1 VDD1 1 Side 1 supply
2-4 INA, INB, INC 1 Side 1 data inputs
5-7 OUTA, OUTB, OUTC 2 Side 2 data outputs
8 GND2 2 Side 2 ground
9 VDD2 2 Side 2 supply
10-12 IND, INE, INF 2 Side 2 data inputs (reverse ch)
13-15 OUTD, OUTE, OUTF 1 Side 1 data outputs (reverse ch)
16 GND1 1 Side 1 ground
  • SPI bus isolation between MCU and high-voltage peripheral
  • Motor drive gate driver isolation
  • Automotive BMS communication isolation
  • Industrial PLC digital I/O isolation
Manufacturer Part Number Package Notes
Silicon Labs Si8630BB-B-IS SOIC-16 Original reference design
TI ISO7730FDWR SOIC-16 TI alternative with similar specs
ADI ADuM3310 SOIC-16 3-ch isolator alternative
