IL485E

NVE IL485E IsoLoop isolated RS-485 transceiver, 2.5kVrms isolation, 35Mbps, 16-SOIC WB

5280

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

IL485E

Package：

SOIC-16 WB

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

MSP430F5304IRGZR

MS9282-1

OP2177ARMZ

NJM2068M

NCF3320EHN

NC7SZ126M5X

MT8870DSR1

MCP6S26-I

Description

Product Overview

The IL485E is an isolated RS-485/RS-422 transceiver from NVE Corporation’s IsoLoop® family. This device integrates a fully featured differential line driver/receiver with 2.5kVrms galvanic isolation using Giant Magnetoresistive (GMR) technology, providing robust serial communication in electrically harsh environments.

Key Specifications

Manufacturer NVE Corporation
Device Type Isolated RS-485/RS-422 Transceiver
Isolation Voltage 2.5 kVrms
Data Rate 35 Mbps (max)
Supply Voltage 3.0V to 5.5V (both sides)
Bus Voltage Range -15V to +15V
Number of Nodes Up to 256
Package SOIC-16 Wide Body
Operating Temperature -40°C to +125°C

Features

  • GMR-based galvanic isolation (IsoLoop technology)
  • 2.5kVrms isolation voltage rating
  • High data rate: up to 35 Mbps
  • Half-duplex RS-485/RS-422 compliant
  • Wide supply range: 3.0V to 5.5V both sides
  • True fail-safe receiver inputs
  • Driver output short-circuit protection
  • Thermal shutdown protection
  • Industrial temperature range

Applications

  • Industrial RS-485 networking
  • Building automation systems
  • Industrial process control
  • HVAC control networks
  • Security and access control systems
  • Isolated sensor interfaces
  • Test and measurement equipment
  • Renewable energy systems

The IL485E is NVE Corporation’s high-speed isolated RS-485/RS-422 transceiver featuring IsoLoop® GMR isolation technology. This device combines a complete RS-485 differential line driver and receiver with 2.5kVrms galvanic isolation in a single 16-pin wide-body SOIC package. Capable of data rates up to 35Mbps, the IL485E is ideal for high-speed industrial communication networks requiring robust galvanic isolation. The device features true fail-safe receiver design, driver short-circuit protection, and thermal shutdown to ensure reliable operation under all conditions. Its wide 3.0V to 5.5V supply range on both sides of the isolation barrier provides maximum design flexibility.

The IL485E uses NVE’s patented IsoLoop Giant Magnetoresistive (GMR) isolation technology to provide signal isolation without the limitations of optocouplers. Digital data is converted into magnetic signals that cross the isolation barrier and are detected by magnetoresistive sensors on the opposite side. This technology offers superior long-term reliability compared to optoelectronic isolation methods. On the bus side, the RS-485 transceiver uses a differential current-steering architecture to drive the A and B bus lines with controlled slew rates for EMC performance. The receiver detects differential voltages on the bus and converts them back to single-ended logic signals on the isolated side.

Pin Number Pin Name Function
1 VDD1 Logic Side Power Supply (3.0-5.5V)
2 RO Receiver Output (Logic Side)
3 DE Driver Enable Input
4 DI Driver Input (Logic Side)
5 GND1 Logic Side Ground
6 NC No Connection
7 NC No Connection
8 NC No Connection
9 GND2 Bus Side Ground
10 A Non-Inverting Bus Line (RS-485 A)
11 B Inverting Bus Line (RS-485 B)
12 NC No Connection
13 NC No Connection
14 NC No Connection
15 RE Receiver Enable Input (Active Low)
16 VDD2 Bus Side Power Supply (3.0-5.5V)
  • Industrial RS-485 and Modbus networks
  • Building automation and HVAC controls
  • Factory floor automation systems
  • Security and access control networks
  • Isolated sensor and transducer interfaces
  • Test and measurement equipment
  • Renewable energy monitoring systems
  • Medical device communication
Model Manufacturer Description
IL485T NVE 250kbps low-speed version
IL488E NVE Full-duplex RS-422 version
ADM2483 Analog Devices Alternative isolated RS-485 transceiver
