IRFB4127PBF

200V N-Channel HEXFET Power MOSFET, 76A, 22 mΩ RDS(on), TO-220AB

6012

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

IRFB4127PBF

Package：

TO-220AB

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

IRLZ44NPBF

IRLR3110ZPBF

IRLML0100TRPBF

IRLML0030TRPBF

IRLR2905TRPBF

IRLH5034TRPBF

IRFS4310ZTRLPBF

IRFS4227TRLPBF

Description

Product Overview

The IRFB4127PBF is a 200V N-channel HEXFET power MOSFET from Infineon Technologies, featuring a continuous drain current of 76A and a maximum on-resistance of 22 mΩ at VGS=10V. Packaged in a TO-220AB through-hole enclosure, this device is optimized for high efficiency power switching and power factor correction applications. The HEXFET technology provides high voltage rating combined with low on-resistance and high current capability, making it suitable for a wide range of industrial and commercial power electronics applications. The device features dynamic dv/dt ruggedness, full avalanche rating, and reliable thermal performance for demanding power supply and motor control designs.

Key Specifications

Drain-Source Voltage (VDS) 200 V
Continuous Drain Current (ID @ 25°C) 76A
Continuous Drain Current (ID @ 100°C) 54A
Pulsed Drain Current (IDM) 300A
On-Resistance (RDS(on) max @ VGS=10V) 22 mΩ
Gate Threshold Voltage (VGS(th)) 2.0 – 4.0 V
Gate-Source Voltage (VGS) ±20 V
Total Gate Charge (Qg typ) 160 nC
Input Capacitance (Ciss typ) 5600 pF
Power Dissipation (PD @ TC=25°C) 300 W
Operating Junction Temperature -55 to +175 °C
Single Pulse Avalanche Energy (EAS) 430 mJ

Features

  • 200V drain-source voltage rating
  • 76A continuous drain current capability
  • 22 mΩ maximum on-resistance at VGS=10V
  • Advanced HEXFET technology
  • Dynamic dv/dt ruggedness rating
  • 175°C operating junction temperature
  • Fast switching speed
  • Fully avalanche rated for reliability
  • Lead-free and RoHS compliant
  • TO-220AB through-hole package

Applications

  • Switch Mode Power Supplies (SMPS)
  • DC-DC converters
  • Motor control and drives
  • Uninterruptible Power Supplies (UPS)
  • Power Factor Correction (PFC)
  • Solar inverter applications
  • Industrial power systems
  • Load switching applications
  • Welding power supplies

The IRFB4127PBF is a 200V N-channel enhancement mode power MOSFET from Infineon Technologies’ HEXFET product family, offering an impressive 76A continuous drain current with a low maximum on-resistance of 22mΩ at VGS=10V. Packaged in a TO-220AB through-hole enclosure, this device provides a compelling combination of high voltage blocking capability, high current handling, and low conduction losses for medium-to-high power switching applications. The IRFB4127PBF features advanced process technology with dynamic dv/dt rating, a 175°C operating junction temperature, fast switching characteristics, and full avalanche rating for enhanced reliability in rugged applications. The device is lead-free and RoHS compliant, making it suitable for a wide range of applications including switch mode power supplies, DC-DC converters, power factor correction, motor control, UPS systems, solar inverters, and industrial power electronics where high performance and reliability are essential.

The IRFB4127PBF is an N-channel enhancement mode MOSFET that operates by creating a conductive channel between drain and source when a positive gate-source voltage exceeds the device threshold (2-4V). At VGS=10V, the MOSFET is fully enhanced with minimum on-resistance (22mΩ max), enabling efficient conduction at high current levels. The HEXFET cell structure maximizes channel density per unit silicon area, achieving this combination of 200V breakdown voltage and low resistance through optimized drift region design and termination structures. With VGS=0V, the device blocks up to 200V across drain-source with minimal leakage current. The integrated body diode allows reverse current conduction when the source is at higher potential than the drain, providing freewheeling capability essential for inductive load circuits. The fully avalanche-rated design ensures the device can safely absorb energy during transient over-voltage conditions, delivering reliable performance in real-world power supply and motor drive applications where unclamped inductive switching events may occur.

Pin Number Pin Name Description
1 Gate (G) Gate control terminal – VGS=10V for full conduction, 0V for off-state
2 Drain (D) Drain terminal – high voltage connection; electrically connected to the mounting tab
3 Source (S) Source terminal – low side return connection
Tab Drain (D) Mounting tab – connected to Pin 2 Drain; primary thermal path to heatsink
  • Switch Mode Power Supplies – primary and secondary side switching
  • DC-DC converters – isolated and non-isolated topologies
  • Motor control – brushless DC and induction motor drives
  • Uninterruptible Power Supplies – inverter and charger stages
  • Power Factor Correction (PFC)
  • Solar inverter applications
  • Industrial power systems – power distribution and control
  • Load switching – high current power distribution systems
  • Welding power supplies
Model VDS (V) ID (A) RDS(on) Max Package
IRFB4020PBF 200 31 68 mΩ TO-220AB
IRFB4229PBF 250 46 46 mΩ TO-220
IRFP260NPBF 200 50 40 mΩ TO-247AC
IRFP460PBF 500 20 270 mΩ TO-247AC
