IRLH5034TRPBF

IRLH5034TRPBF - 40V N-Channel Trench ULV Power MOSFET, 2.4 mΩ @ 10V; 3.2 mΩ @ 4.5V RDS(on), PQFN 5x6mm

3309

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

IRLH5034TRPBF

Package：

PQFN 5x6mm

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

IRLZ44NPBF

IRLR3110ZPBF

IRLML0100TRPBF

IRLML0030TRPBF

IRLR2905TRPBF

IRFS4310ZTRLPBF

IRFS4227TRLPBF

IRFS4115TRLPBF

Description

Product Overview

The IRLH5034TRPBF is a 40V N-Channel Trench ULV Power MOSFET from Infineon Technologies (formerly International Rectifier), part of the Trench ULV Technology product family. This device combines optimized silicon processing with industry-standard packaging to deliver reliable performance for demanding power electronics applications. The IRLH5034TRPBF provides a well-balanced combination of voltage rating, current handling, and on-resistance, making it suitable for a wide range of power conversion and switching applications.

Manufactured using advanced power MOSFET technology, the IRLH5034TRPBF features a rugged design with fully characterized avalanche performance and dynamic dv/dt capability. The device is available in a PQFN 5x6mm package, offering proven thermal performance and board-level reliability for volume production environments.

Key Specifications

Drain-Source Voltage (VDS) 40 V
Continuous Drain Current (ID @ 25°C) 100A
Pulsed Drain Current (IDM) 400A
On-Resistance (RDS(on) max @ VGS=10V) 2.4 mΩ @ 10V; 3.2 mΩ @ 4.5V
Gate Threshold Voltage (VGS(th)) 1.0 – 2.5 V
Gate-Source Voltage (VGS) ±16 V
Total Gate Charge (Qg) 43 nC (typ) @ 4.5V
Power Dissipation (PD) 100W (PCB mounted)
Operating Junction Temperature -55 to +150 °C
Package PQFN 5x6mm

Features

  • 40 V drain-source voltage rating
  • Advanced Trench ULV Technology
  • Low RDS(on), low thermal resistance to PCB, low profile ≤0.9mm
  • Dynamic dv/dt ruggedness rating
  • 175°C operating junction temperature (where applicable)
  • Fast switching speed
  • Fully avalanche rated for reliability
  • Lead-free and RoHS compliant
  • PQFN 5x6mm package

Applications

  • Secondary side synchronous rectification, DC motor inverters, DC-DC brick apps
  • Switch Mode Power Supplies (SMPS)
  • DC-DC converters
  • Motor control and drives
  • Power management systems
  • Industrial power systems
  • Load switching applications

The IRLH5034TRPBF is an N-channel enhancement mode power MOSFET from Infineon Technologies’ Trench ULV Technology family. It features a drain-source voltage rating of 40 V and continuous drain current of 100A with a maximum on-resistance of 2.4 mΩ @ 10V; 3.2 mΩ @ 4.5V. Packaged in a PQFN 5x6mm, this device is optimized for secondary side synchronous rectification, dc motor inverters, dc-dc brick apps. The IRLH5034TRPBF provides low rds(on), low thermal resistance to pcb, low profile ≤0.9mm, along with fully characterized avalanche performance and industry-standard packaging for ease of design and manufacturing.

The IRLH5034TRPBF operates as an N-channel enhancement-mode MOSFET. When a positive gate-source voltage exceeding the threshold (1.0 – 2.5 V) is applied, an N-type inversion layer forms in the P-type body region, creating a conductive channel between drain and source. At VGS=10V, the device reaches full enhancement, providing its rated on-resistance of 2.4 mΩ @ 10V; 3.2 mΩ @ 4.5V. The Trench ULV Technology cell geometry balances switching speed with conduction losses. With VGS=0V, the device blocks up to 40 V across the drain-source junction with minimal leakage. The intrinsic body diode provides reverse conduction capability, essential for inductive load applications such as motor drives and power supply converters.

Pin Number Pin Name Description
1 Gate (G) Gate control terminal – VGS=10V for full conduction, 0V for off-state
2 Drain (D) Drain terminal – high voltage connection
3 Source (S) Source terminal – low side return connection
Tab Drain (D) Mounting tab – connected to Drain; primary thermal path
  • Secondary side synchronous rectification, DC motor inverters, DC-DC brick apps
  • Switch Mode Power Supplies (SMPS)
  • DC-DC converters – isolated and non-isolated topologies
  • Motor control – brushless DC and induction motor drives
  • Power management systems
  • Industrial power systems
  • Load switching applications
Model VDS (V) ID (A) RDS(on) Max Package
Check distributor — — — —
