MAX1748EUE+T

28V boost DC-DC, 2.6~5.5V in, 1.5A/0.15Ω FET, 1.2MHz, 95% eff, TSSOP-16-EP, -40~85°C

7890

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

MAX1748EUE+T

Package：

16-pin TSSOP-EP (5.0 x 4.4 mm)

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

MSP430F5304IRGZR

MS9282-1

OP2177ARMZ

NJM2068M

NCV887103D1R2G

NCF3320EHN

NC7SZ126M5X

NAE12S17-A

Description

Product Overview

The MAX1748EUE+T is a high-efficiency step-up DC-DC converter from Analog Devices (Maxim Integrated) designed for OLED display bias voltage generation. It integrates a 1.5A, 0.15Ω n-channel MOSFET and operates from 2.6V to 5.5V input, producing up to 28V output at 95% efficiency. The EUE+T variant is in a 16-pin TSSOP-EP package with tape & reel and -40°C to +85°C temperature range.

Key Specifications

Function Step-up DC-DC converter (boost)
Input Voltage 2.6V to 5.5V
Output Voltage Up to 28V (adjustable)
Output Current Up to 1.5A (switch current)
Switch RDS(ON) 0.15Ω
Efficiency Up to 95%
Switching Frequency 1.2 MHz
Operating Mode PWM / PFM (auto)
Operating Temp -40°C to +85°C
Package 16-pin TSSOP-EP (exposed pad)
Packing Tape & Reel
Part Status Active

Features

  • High-efficiency 28V boost converter for OLED bias
  • 1.5A, 0.15Ω integrated n-FET
  • 1.2 MHz fixed switching frequency
  • 2.6V to 5.5V input range
  • Up to 95% efficiency
  • PWM/PFM auto-mode for light-load efficiency
  • Adjustable output voltage
  • Overcurrent and thermal shutdown protection
  • Small 16-pin TSSOP-EP package

Applications

  • OLED display positive bias (VDD) generation
  • Smartphone and wearable OLED power
  • LCD bias voltage generation
  • White LED driver for display backlight

The MAX1748EUE+T is a high-efficiency 28V step-up DC-DC converter from Analog Devices (Maxim) designed for OLED display bias voltage generation. It integrates a 1.5A, 0.15Ω n-channel MOSFET and operates from 2.6V to 5.5V input with up to 95% efficiency. The 1.2 MHz fixed frequency allows small external inductors and capacitors. PWM/PFM auto-mode maintains efficiency at light loads. The 16-pin TSSOP-EP package with exposed thermal pad and tape & reel packing suit high-volume mobile and wearable OLED applications.

The MAX1748 uses a current-mode PWM boost converter topology. The integrated n-channel MOSFET switches the inductor current at 1.2 MHz. During MOSFET on-time, inductor current ramps up storing energy. During off-time, inductor energy transfers to the output through the external Schottky diode. Current-mode control provides fast transient response and cycle-by-cycle current limiting. At light loads, the controller automatically switches to PFM (pulse-frequency modulation) mode to reduce switching losses and maintain high efficiency. Output voltage is set by an external resistor divider feedback network.

Pin Name Function
– IND Inductor connection (drain of internal FET)
– FB Feedback input for output voltage regulation
– COMP Compensation input for error amplifier
– SHDN Shutdown control (active low)
– VCC Supply voltage
– GND Ground and thermal pad
  • Smartphone AMOLED positive bias (AVDD ~8.6V)
  • Wearable OLED display power supply
  • Tablet OLED panel bias generation
  • LCD positive/negative bias rail
Manufacturer Part Number Package Notes
TI TPS61322 WQFN OLED bias boost alternative
Silergy SY7208ABC SOT-23-6 Compact OLED boost alternative
