Description

Product Overview

The PIC16C621-04 is a 18-pin 8-bit CMOS microcontroller from Microchip Technology’s mid-range PIC16 family, offering a cost-effective OTP solution for high-volume embedded control applications. Featuring 1024 words of One-Time Programmable (OTP) program memory, 80 bytes of RAM, and a versatile set of peripherals including two 8-bit timers, an analog comparator module, and up to 16 I/O pins, this device provides good functionality at an economical price point. The 04 suffix indicates a 4 MHz operating frequency, suitable for a wide range of consumer, automotive, and industrial applications where in-field reprogrammability is not required.

Key Specifications

Core Architecture PIC RISC (8-bit, mid-range)
Program Memory 1024 words (OTP – One Time Programmable)
RAM (Data Memory) 80 bytes
EEPROM None
Oscillator Options RC, LP, XT, HS, EC
Max Clock Frequency 4 MHz (04 variant)
Supply Voltage 2.5V to 6.0V
I/O Pins Up to 16
Timers TMR0 (8-bit) + TMR1 (16-bit)
Analog Comparators 2 (comparator module)
Operating Temperature 0°C to +70°C (Commercial)
Package Type PDIP-18 / SOIC-18 / SSOP-20

Features

  • 1024 words of OTP program memory
  • 80 bytes of general-purpose RAM
  • Dual analog comparators
  • 16-bit Timer1 + 8-bit Timer0
  • Up to 16 I/O pins with individual direction control
  • Interrupt capability (multiple sources)

Applications

  • High-volume consumer electronics
  • Appliance controllers
  • Power supply supervisors
  • Automotive body electronics
  • LED display drivers
  • Motor control (simple)
  • Security system sensors

The PIC16C621-04 is an 18-pin member of Microchip’s PIC16C mid-range family of 8-bit microcontrollers, featuring OTP (One-Time Programmable) program memory for cost-optimized high-volume production. Built on the proven PIC16 architecture with a 14-bit instruction word and 35 instructions, this device provides a well-balanced mix of I/O, memory, and analog peripherals at an economical price point. The dual analog comparator module allows for voltage monitoring, zero-crossing detection, and simple analog signal processing without requiring an external comparator IC. With 1024 words of program memory and 80 bytes of RAM, the PIC16C621 offers sufficient resources for moderately complex control applications including state machines, timing functions, and basic decision logic. The 16 available I/O pins—organized as two 8-bit ports—provide generous connectivity for interfacing with sensors, switches, LEDs, and other external circuitry. The dual timer architecture (8-bit Timer0 plus 16-bit Timer1) supports a variety of timing and counting applications, with Timer1 capable of running from an external 32 kHz crystal for low-power real-time clock functions. The OTP memory model makes this device ideal for mature, high-volume products where the firmware is well established and no in-field updates are anticipated, providing the lowest possible cost per unit. The 04 speed grade supports operation up to 4 MHz, delivering a 1 MHz instruction cycle rate.

The PIC16C621-04 operates on Microchip’s mid-range PIC Harvard architecture, featuring separate program and data memory buses accessed in parallel for maximum throughput. The 14-bit wide instructions support 35 unique operations, most executing in a single instruction cycle (4 oscillator periods). An 8-level deep hardware stack supports subroutine calls and interrupt handling. Program memory consists of 1024 words of OTP ROM, programmed once during manufacturing using a device programmer. The data memory is divided into banks containing 80 bytes of general-purpose registers plus Special Function Registers (SFRs) for controlling the various peripheral modules. The dual analog comparator module provides two independent comparators with multiplexed input/output configurations, supporting modes such as two independent comparators, window comparator, or comparator with reference. Timer0 is an 8-bit timer/counter with a programmable prescaler, configurable for either internal clock (timer mode) or external input (counter mode). Timer1 is a 16-bit timer/counter with its own prescaler and the ability to run asynchronously from a secondary oscillator. The interrupt system supports multiple sources including external interrupt, Timer0 overflow, Timer1 overflow, and comparator output change, enabling efficient event-driven programming. I/O ports are individually configurable as inputs or outputs, with TTL input levels and CMOS output drivers capable of sourcing/sinking significant current.

Pin Group Pins Type Function
RA0-RA5 6 I/O Port A – 6 bidirectional I/O pins (some with analog functions)
RB0-RB7 8 I/O Port B – 8 bidirectional I/O pins (RB0 = INT, RB4-RB7 = IOC)
MCLR 1 Input Master Clear / Reset input (active low)
OSC1 / CLKIN 1 Input Oscillator input / External clock input
OSC2 / CLKOUT 1 Output Oscillator output / Clock output (Fosc/4)
VDD / VSS 2 Power Positive supply and ground
  • High-volume consumer appliance controllers
  • Power supply monitoring and protection circuits
  • Automotive interior lighting and accessory control
  • 7-segment and LED matrix display drivers
  • DC fan and simple motor speed controllers
  • Security system sensor interface modules
Manufacturer Part Number Package Notes
Microchip PIC16F627A SOIC-18 Flash version, 1024W, same peripherals
Microchip PIC16C622 PDIP-18 2048W OTP, more program memory
Zilog Z86E0208 DIP-18 Z8 core, 2KB OTP, alternative architecture
Atmel AT90S2313 DIP-20 AVR core, 2KB Flash, similar pin count
