PIC16C622-04

18-pin OTP MCU, 2048W program, 128B RAM, dual comparators, 4MHz, PIC16 architecture

4800

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

PIC16C622-04

Package：

PDIP-18 (6.35 x 22.86 x 3.3 mm) / SOIC-18

Brand：
Product Categories：

Quality Commitment

Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

STM32L053C8T6

STM32L052R8T6

STM32L010C6T6

STM32H7A3ZIT6

STM32H745ZIT6

STM32H743BIT6

STM32G030F6P6TR

STM32F767IIT6

Description

Product Overview

The PIC16C622-04 is an 18-pin 8-bit OTP microcontroller offering double the program memory of the PIC16C621, with 2048 words of One-Time Programmable memory and a robust peripheral set including dual analog comparators and two timers. Part of Microchip’s PIC16 mid-range family, this device provides a cost-effective solution for moderately complex embedded control applications requiring more program space. The 04 speed grade operates at up to 4 MHz, delivering a 1 MHz instruction cycle rate suitable for consumer appliances, automotive electronics, industrial control, and security systems.

Key Specifications

Core Architecture PIC RISC (8-bit, mid-range)
Program Memory 2048 words (OTP – One Time Programmable)
RAM (Data Memory) 128 bytes
EEPROM None
Oscillator Options RC, LP, XT, HS, EC
Max Frequency 4 MHz (04 variant)
Supply Voltage 2.5V to 6.0V
I/O Pins Up to 16
Timers TMR0 (8-bit) + TMR1 (16-bit)
Analog Comparators 2 modules
Operating Temperature 0°C to +70°C (Commercial)
Package Type PDIP-18 / SOIC-18 / SSOP-20

Features

  • 2048 words OTP program memory (double PIC16C621)
  • 128 bytes of general-purpose RAM
  • Dual analog comparators with multiple modes
  • 16-bit Timer1 + 8-bit Timer0
  • 16 I/O pins with interrupt-on-change
  • External interrupt pin (RB0/INT)
  • Watchdog Timer with independent oscillator
  • Power-on Reset and Power-up Timer
  • Wide voltage range: 2.5V to 6.0V

Applications

  • Consumer appliance control
  • HVAC and climate control
  • Automotive body modules
  • Security and alarm systems
  • Industrial sensor interfaces
  • Motor and actuator control
  • Display panel controllers

The PIC16C622-04 is an 18-pin member of Microchip’s PIC16C family of 8-bit microcontrollers, featuring 2048 words of One-Time Programmable (OTP) program memory—twice the capacity of the PIC16C621. This expanded memory allows for more complex application code, state machines, and control algorithms to be implemented in a cost-effective OTP form factor. Built on the proven 14-bit mid-range PIC architecture with 35 instructions, the device also features 128 bytes of general-purpose RAM, providing increased data storage for variables, buffers, and intermediate calculations. The dual analog comparator module offers flexible configuration options including two independent comparators, a window comparator, or a single comparator with internal voltage reference. The 16 general-purpose I/O pins—divided between Port A (6 pins) and Port B (8 pins)—provide ample connectivity for interfacing with external components, with Port B supporting interrupt-on-change on the upper nibble and a dedicated external interrupt pin (RB0/INT). The dual timer architecture supports a wide range of timing applications, from simple delay generation to event counting and pulse width measurement. The OTP memory model is ideal for high-volume production of mature products where firmware stability has been proven, offering the lowest possible unit cost. The 04 speed grade supports operation up to 4 MHz with a wide supply voltage range of 2.5V to 6.0V.

The PIC16C622-04 executes instructions using Microchip’s mid-range PIC Harvard architecture, with separate 14-bit program and 8-bit data memory buses operating in parallel through a two-stage fetch-execute pipeline. Most of the 35 instructions execute in a single instruction cycle (4 oscillator periods), yielding a 1 MIPS execution rate at 4 MHz clock frequency. The 2048-word OTP program memory is addressed by a 11-bit program counter, with an 8-level deep hardware stack for subroutine calls and interrupt context saving. Data memory is organized in banks containing 128 bytes of general-purpose file registers plus Special Function Registers for peripheral control and status. The dual comparator module features two analog comparators with multiplexed inputs and outputs, configurable through the CMCON register for various operating modes. Timer0 is an 8-bit timer/counter with an 8-bit prescaler, capable of counting internal instruction cycles or external events. Timer1 is a 16-bit timer/counter with a programmable prescaler and support for asynchronous operation from a secondary low-frequency crystal oscillator, enabling real-time clock functionality even in Sleep mode. The interrupt controller manages multiple interrupt sources including external interrupt (INT), Timer0 overflow, Timer1 overflow, and comparator output change, allowing efficient event-driven programming. I/O ports feature TTL input buffers and CMOS output drivers with individual direction control per pin.

Pin Name Type Function
1-2 RA0-RA1 I/O Port A bits 0-1 (analog comparator inputs)
3 RA2 / T0CKI I/O Port A bit 2 / Timer0 external clock input
4 RA3 / MCLR Input Port A bit 3 / Master Clear reset
5-6 RA4-RA5 I/O Port A bits 4-5 (RA4 = T0CKI alternate, comparator outputs)
7 VSS Power Ground reference
8-15 RB0-RB7 I/O Port B – 8 I/O pins (RB0=INT, RB4-RB7=IOC)
16 OSC2 / CLKOUT Output Oscillator output / Fosc/4 clock output
17 OSC1 / CLKIN Input Oscillator input / External clock input
18 VDD Power Positive supply voltage (2.5V to 6.0V)
  • Home appliance control panels and cooking controllers
  • HVAC thermostat and climate control modules
  • Automotive body control and lighting modules
  • Burglar alarm and fire safety system controllers
  • Industrial proximity sensor and limit switch interfaces
  • Stepper motor and solenoid actuator control circuits
Manufacturer Part Number Package Notes
Microchip PIC16F628A SOIC-18 Flash version, 2KB, same pinout, reprogrammable
Microchip PIC16F648A SOIC-18 4KB Flash, 256B RAM, enhanced version
Atmel ATmega8 PDIP-18 AVR core, 8KB Flash, ADC, more powerful
STC STC89C52RC PDIP-20 8051 core, 8KB Flash, alternative architecture
