Product Overview
The PIC16C63A-04I is a 28-pin 8-bit OTP microcontroller from Microchip Technology featuring the Universal Synchronous/Asynchronous Receiver Transmitter (USART) serial communication module. With 4096 words of One-Time Programmable program memory, 192 bytes of RAM, two analog comparators, three timer/counters, and up to 22 I/O pins, this device provides robust functionality for embedded applications requiring serial communication. The industrial temperature variant operates reliably from -40°C to +85°C, making it suitable for industrial networking, data loggers, and distributed control systems.
Key Specifications
| Core Architecture | PIC RISC (8-bit, mid-range) |
| Program Memory | 4096 words (OTP) |
| RAM (Data Memory) | 192 bytes |
| EEPROM | None |
| Serial Communication | USART (UART/SCI) |
| Oscillator Options | RC, LP, XT, HS, EC |
| Max Frequency | 4 MHz (04I variant) |
| Supply Voltage | 2.5V to 6.0V |
| I/O Pins | Up to 22 |
| Timers | TMR0 (8-bit), TMR1 (16-bit), TMR2 (8-bit) |
| Analog Comparators | 2 modules |
| Operating Temperature | -40°C to +85°C (Industrial) |
| Package Type | PDIP-28 / SOIC-28 / SSOP-28 |
Features
- 4096 words OTP program memory
- 192 bytes RAM
- USART module (UART/SCI)
- Dual analog comparators
- 3 timers: TMR0, TMR1, TMR2
- 22 I/O pins with interrupt-on-change
- Watchdog Timer
- Industrial temperature range
Applications
- Industrial serial communication modules
- Data acquisition and logging systems
- RS-232/RS-485 interface converters
- Distributed sensor networks
- Industrial control panels
- Smart meter communication modules
- Networked sensor nodes
The PIC16C63A-04I is a 28-pin member of Microchip’s PIC16C mid-range microcontroller family, distinguished by its integrated USART (Universal Synchronous/Asynchronous Receiver Transmitter) serial communication module. This hardware serial port enables reliable, high-speed serial communication with minimal CPU overhead, making the device ideal for applications requiring RS-232, RS-485, or other serial protocol connectivity. With 4096 words of OTP program memory and 192 bytes of RAM, the PIC16C63A provides substantial resources for moderately complex applications including protocol stacks, data buffering, and control logic. The three-timer architecture (8-bit TMR0, 16-bit TMR1, 8-bit TMR2) supports versatile timing functions, with TMR2 specifically designed to work with the CCP module for PWM generation and capture/compare operations. The dual analog comparator module provides analog signal processing capability for voltage monitoring and threshold detection. With 22 general-purpose I/O pins distributed across three ports (PORTA, PORTB, PORTC), the device offers generous connectivity for external peripherals and user interfaces. The industrial temperature grade (-40°C to +85°C) ensures reliable performance in harsh industrial and automotive environments. The OTP memory model provides cost-effective solutions for high-volume production with mature firmware.
The PIC16C63A-04I is built on Microchip’s mid-range PIC Harvard architecture with a 14-bit instruction word and 35 instructions. Separate program and data buses operate concurrently through a two-stage pipeline, achieving single-cycle execution for most instructions. At 4 MHz clock frequency, the instruction cycle rate is 1 MHz (1 MIPS). The 4096-word OTP program memory is addressed by a 12-bit program counter with an 8-level deep hardware stack for subroutine and interrupt handling. The USART module provides full-duplex asynchronous serial communication (UART mode) and half-duplex synchronous communication (SPI-like mode). In asynchronous mode, it supports standard baud rates from 300 to 19200+ baud (depending on clock frequency), with 8-bit data, optional parity, and 1 or 2 stop bits. The baud rate generator uses either Timer1 (8-bit mode) or a dedicated 16-bit baud rate generator register (BRGH mode). Timer0 (8-bit), Timer1 (16-bit), and Timer2 (8-bit with period register) provide flexible timing and PWM generation capabilities. The dual comparator module supports multiple configuration modes. The interrupt system supports sources including external interrupt, timer overflows, USART receive/transmit, and comparator output change. I/O ports are individually configurable with TTL input levels and CMOS output drivers.
Pin Group Pins Type Function RA0-RA5 6 I/O Port A – 6 I/O (analog comparator inputs/outputs) RB0-RB7 8 I/O Port B – 8 I/O (INT on RB0, IOC on RB4-RB7) RC0-RC7 8 I/O Port C – 8 I/O (USART: RC6=TX, RC7=RX; TMR1 oscillator) MCLR 1 Input Master Clear / Reset (active low) OSC1 / CLKIN 1 Input Oscillator input / External clock OSC2 / CLKOUT 1 Output Oscillator output / Fosc/4 output VDD / VSS 2 Power Power supply and ground (multiple pins) - Industrial RS-485/Modbus communication nodes
- Multi-channel data loggers with serial upload
- Serial protocol converters (RS-232 to proprietary)
- Distributed industrial sensor network controllers
- Smart electricity/gas/water meter communication modules
- Building automation sensor and actuator interfaces
