PIC16C63A-20

High-speed 28-pin OTP MCU with USART, 20MHz/5MIPS, 4096W program, 192B RAM, commercial grade

4500

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

PIC16C63A-20

Package：

PDIP-28 / SOIC-28 (7.5 x 17.9 x 2.3 mm) / SSOP-28

Brand：
Product Categories：

Quality Commitment

Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

STM32L053C8T6

STM32L052R8T6

STM32L010C6T6

STM32H7A3ZIT6

STM32H745ZIT6

STM32H743BIT6

STM32G030F6P6TR

STM32F767IIT6

Description

Product Overview

The PIC16C63A-20 is a high-speed 28-pin 8-bit OTP microcontroller with integrated USART serial communication, operating at up to 20 MHz clock frequency for 5 MIPS performance. Featuring 4096 words of One-Time Programmable program memory, 192 bytes of RAM, dual analog comparators, and three timer/counters, this high-speed variant enables faster serial baud rates, quicker response times, and more computationally intensive operations. The commercial temperature grade is well-suited for consumer electronics, data communication, and high-speed control applications.

Key Specifications

Core Architecture PIC RISC (8-bit, mid-range)
Program Memory 4096 words (OTP)
RAM (Data Memory) 192 bytes
EEPROM None
Serial Communication USART (UART / Sync Serial)
Max Clock Frequency 20 MHz (20 variant)
MIPS Performance 5 MIPS @ 20 MHz
Supply Voltage 4.5V to 5.5V (20 MHz)
I/O Pins Up to 22
Timers TMR0, TMR1 (16-bit), TMR2
Analog Comparators 2 modules
Operating Temperature 0°C to +70°C (Commercial)
Package Type PDIP-28 / SOIC-28 / SSOP-28

Features

  • 20 MHz high-speed operation (5 MIPS)
  • 4096 words OTP program memory
  • Integrated USART with high baud rate support
  • 192 bytes general-purpose RAM
  • Dual analog comparators
  • 3 timer/counters (TMR0, TMR1, TMR2)
  • 22 I/O pins with interrupt capability
  • Wide 4.5-5.5V operating range at full speed
  • Watchdog Timer with built-in oscillator

Applications

  • High-speed serial data communication
  • Protocol conversion and data routing
  • Fast data acquisition systems
  • High-speed motor control
  • USB-to-serial bridges
  • Industrial automation controllers
  • Telecommunications equipment
  • High-resolution LED display drivers

The PIC16C63A-20 is the high-speed 20 MHz variant of Microchip’s PIC16C63A 28-pin microcontroller, delivering 5 MIPS of processing performance—five times the execution speed of the 4 MHz variant. This increased performance enables higher baud rate serial communication, faster control loop response, more complex signal processing, and higher resolution timing measurements. The integrated USART module supports significantly higher baud rates at 20 MHz, up to 115.2 kbps and beyond with the high-speed baud rate generator mode, making it suitable for demanding serial communication applications. With 4096 words of OTP program memory and 192 bytes of RAM, the device provides ample resources for complex application code, communication protocol stacks, and data buffers. The three-timer architecture (8-bit TMR0, 16-bit TMR1, 8-bit TMR2) supports precision timing and PWM generation at higher resolutions than slower speed grades. The dual analog comparator module adds analog signal processing capability. The 22 I/O pins provide generous connectivity, with interrupt-on-change capability on Port B and a dedicated external interrupt pin. The commercial temperature rating (0°C to +70°C) covers most consumer and indoor industrial applications. The OTP memory model is ideal for high-volume production with proven firmware, offering excellent cost-performance ratio for high-speed applications.

The PIC16C63A-20 operates on Microchip’s mid-range PIC Harvard architecture with a 14-bit instruction set and 35 instructions. At 20 MHz clock frequency, the 4-cycle per instruction architecture yields a 5 MIPS execution rate, five times faster than the 4 MHz variant. The two-stage pipeline overlaps instruction fetch and execution, maximizing throughput. The 4096-word OTP program memory is addressed by a 12-bit program counter with an 8-level deep hardware stack for subroutine calls and interrupt service routines. The USART (Universal Synchronous/Asynchronous Receiver Transmitter) module provides full-duplex serial communication. At 20 MHz with the high-speed baud rate generator enabled (BRGH=1), the device can achieve baud rates up to 1250000 baud (1.25 Mbps) in asynchronous mode, supporting very high-speed serial data transfer. Standard rates such as 115200, 57600, and 38400 baud are also supported with good accuracy. Timer0 (8-bit), Timer1 (16-bit), and Timer2 (8-bit) each have prescalers and can be configured for various timing functions including PWM generation and input capture. The dual comparator module provides analog signal comparison with multiple configuration modes. The interrupt system handles multiple sources including USART TX/RX, timer overflows, external interrupt, and comparator output changes, enabling efficient event-driven programming at high speeds.

Pin Group Count Type Function
RA0-RA5 6 I/O Port A: 6 I/O pins with analog comparator functions
RB0-RB7 8 I/O Port B: 8 I/O pins (RB0=INT, RB4-RB7=IOC interrupt)
RC0-RC7 8 I/O Port C: 8 I/O (RC6=TX/CK, RC7=RX/DT for USART; T1OSO/T1OSI)
MCLR / VPP 1 Input Master Clear Reset / Programming voltage
OSC1 / CLKIN 1 Input Oscillator crystal input / External clock input
OSC2 / CLKOUT 1 Output Oscillator crystal output / Fosc/4 clock output
VDD 2 Power Positive supply pins (pins 1 and 20)
VSS 2 Power Ground pins (pins 8 and 19)
  • High-speed RS-232/RS-485 serial data transfer modules
  • Serial protocol converters and data routing devices
  • Fast multi-channel data acquisition front-ends
  • High-speed stepper and DC motor controllers
  • USB to UART bridge and interface adapters
  • High-refresh-rate LED matrix display controllers
Manufacturer Part Number Package Notes
Microchip PIC16F877A PDIP-40 Flash, 8KB, ADC + USART + SPI/I2C, more peripherals
Atmel ATmega328P TQFP-32 AVR core, 20MHz, 32KB Flash, ADC, USART
NXP LPC824 TSSOP-20 Cortex-M0+, 32KB Flash, USART, 32-bit
Silicon Labs EFM8BB52 QFN-28 8051 core, 50MHz, 64KB Flash, USB
