PIC16F1823-I

14-pin MCU, 7KB Flash, 10-bit ADC, mTouch capacitive touch, EUSART+SPI+I2C, 4 PWM, 32MHz, industrial

6700

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

PIC16F1823-I

Package：

SOIC-14 (3.9 x 8.65 x 1.5 mm) / TSSOP-14 / QFN-16

Brand：
Product Categories：

Quality Commitment

Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

STM32L053C8T6

STM32L052R8T6

STM32L010C6T6

STM32H7A3ZIT6

STM32H745ZIT6

STM32H743BIT6

STM32G030F6P6TR

STM32F767IIT6

Description

Product Overview

The PIC16F1823-I is a 14-pin enhanced mid-range 8-bit Flash microcontroller featuring a comprehensive peripheral set including a 10-bit ADC, EUSART, MSSP (SPI/I²C), multiple CCP/PWM modules, and mTouch capacitive touch sensing capability. With 7 KB of Flash program memory, 256 bytes of RAM, 256 bytes of EEPROM, and an integrated high-accuracy internal oscillator, this device offers excellent value for compact embedded control applications. The industrial temperature variant operates reliably from -40°C to +85°C, making it suitable for consumer electronics, industrial control, LED lighting, and touch-sensitive user interfaces.

Key Specifications

Core Architecture PIC RISC (enhanced mid-range, 14-bit)
Flash Program Memory 7 KB (4096 words)
RAM (Data Memory) 256 bytes
EEPROM 256 bytes
ADC Resolution 10-bit, 10 channels
Capacitive Touch mTouch support (up to 9 channels)
Internal Oscillator 32 MHz (±1% calibrated)
Supply Voltage 1.8V to 5.5V
I/O Pins 12
Serial Ports EUSART + MSSP (SPI/I²C)
PWM/CCP 2 CCP + 2 PWM modules
Timers TMR0, TMR1 (16-bit), TMR2
Operating Temperature -40°C to +85°C (Industrial)
Package Type SOIC-14 / TSSOP-14 / QFN-16

Features

  • 10-bit ADC with 10 analog channels
  • mTouch capacitive touch sensing support
  • 7KB Flash + 256B RAM + 256B EEPROM
  • 32 MHz high-accuracy internal oscillator
  • EUSART + MSSP (SPI/I²C) serial ports
  • 4 PWM channels (2 CCP + 2 ECCP)
  • Data Signal Modulator (DSM)
  • Wide voltage range: 1.8V to 5.5V
  • Industrial temperature range

Applications

  • Capacitive touch buttons and sliders
  • LED lighting control and dimming
  • Consumer electronics interfaces
  • Smart home devices
  • Industrial sensor nodes
  • Battery-powered portable devices
  • Appliance user interfaces
  • Remote controls

The PIC16F1823-I is a 14-pin member of Microchip’s PIC16F18xx family of enhanced mid-range 8-bit microcontrollers, offering an impressive array of peripherals for its size including capacitive touch sensing capability, multiple PWM channels, and dual serial communication ports. With 7 KB of Flash program memory, 256 bytes of RAM, and 256 bytes of EEPROM, this device provides a well-balanced mix of memory resources for compact embedded designs. The integrated 10-bit ADC with 10 analog channels supports not only conventional analog voltage measurement but also Microchip’s mTouch capacitive touch sensing technology, enabling the implementation of touch buttons, sliders, and proximity sensors without external touch controller ICs. The four PWM channels (two CCP and two ECCP modules) provide flexible waveform generation for LED dimming, motor control, and power supply applications. The EUSART and MSSP (SPI/I²C) serial ports enable connectivity to a wide range of external devices and communication networks. The 32 MHz internal oscillator—factory calibrated to ±1% accuracy—delivers 8 MIPS of processing performance while eliminating the need for external crystals in most applications. The wide 1.8V to 5.5V operating voltage range and low-power sleep modes make this device suitable for battery-powered applications. The industrial temperature rating ensures reliable operation across a broad range of environmental conditions.

The PIC16F1823-I is built on Microchip’s enhanced mid-range PIC architecture with a 14-bit instruction set and a 16-level deep hardware stack. At 32 MHz system clock frequency, the device achieves 8 MIPS of processing performance with the standard 4-cycle per instruction execution. The 10-bit ADC module features a successive approximation architecture with 10 multiplexed analog input channels. For capacitive touch sensing, the ADC is used in conjunction with the Fixed Voltage Reference (FVR) and the Charge Time Measurement Unit (CTMU) to measure the capacitance of touch pads—when a finger approaches, the capacitance changes and this change is detected by the measurement circuit. Microchip’s mTouch firmware libraries implement the touch detection algorithm, providing robust touch detection with noise immunity and automatic calibration. The EUSART module supports full-duplex UART communication with features including auto-baud detection and wake-up on break. The MSSP module provides both SPI and I²C serial interface support. The CCP (Capture/Compare/PWM) and ECCP (Enhanced CCP) modules support input capture, output compare, and PWM waveform generation with up to 10-bit resolution. The Data Signal Modulator (DSM) module can modulate a carrier signal with a data signal, useful for IR communication and other signaling applications. Multiple power-saving modes including Sleep, Doze, and Idle enable significant power reduction for battery-operated devices.

Pin Name Type Primary Functions
1 VDD Power Positive supply voltage (1.8V to 5.5V)
2 RA5 / AN4 / CCP2 I/O RA5 / ADC CH4 / CCP2 output
3 RA4 / AN3 / CCP1 I/O RA4 / ADC CH3 / CCP1 output
4 RA3 / MCLR / VPP Input RA3 / Master Clear / Programming voltage
5 RA2 / AN2 / T0CKI I/O RA2 / ADC CH2 / Timer0 clock
6 RA1 / AN1 / VREF- I/O RA1 / ADC CH1 / ADC negative reference
7 RA0 / AN0 / VREF+ I/O RA0 / ADC CH0 / ADC positive reference
8 VSS Power Ground reference (0V)
9 RB0 / AN10 / INT I/O RB0 / ADC CH10 / External interrupt
10 RB1 / RX / AN9 I/O RB1 / EUSART RX / ADC CH9
11 RB2 / TX / AN8 / SCK I/O RB2 / EUSART TX / ADC CH8 / SPI clock
12 RB3 / CCP2 / AN7 / SDI I/O RB3 / CCP2 / ADC CH7 / SPI data in
13 RB4 / SDO / AN6 I/O RB4 / SPI data out / ADC CH6
14 RB5 / SCL/SDA / AN5 I/O RB5 / I2C clock/data / ADC CH5
  • Capacitive touch button and slider interfaces for appliances
  • Multi-channel LED dimming and color control systems
  • Consumer electronics user interface controllers
  • Smart home touch panels and remote control devices
  • Battery-powered portable sensor and touch devices
  • White goods control panels with touch interface
Manufacturer Part Number Package Notes
Microchip PIC16F1827 SOIC-18 7KB Flash, 16 I/O, same feature set, more pins
Silicon Labs C8051F850 SOIC-16 8051 core, 8KB Flash, 12-bit ADC, capacitive touch
STMicro STM8L101 TSSOP-14 STM8, 2KB Flash, 10-bit ADC, ultra low power
TI MSP430G2452 TSSOP-14 16-bit, 8KB Flash, 10-bit ADC, low power
