QMC5883L

3-axis AMR magnetic sensor, +/-8G range, 16-bit resolution, I2C interface up to 400kHz, built-in SET/RESET, integrated t

10158

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

QMC5883L

Package：

LGA-16 (3.0x3.0x0.9mm)

Brand：
Product Categories：

Quality Commitment

Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

RM5532AL

RDA5856TE

RA80H1415M1

R5F109BCK

R2A20178NP

PS2805C-1-F3-A

PIC32MZ1024ECG100-I

PIC32MX795F512L-80I

Description

Product Overview

The QMC5883L is a high-performance electronic component from QST, featuring a LGA-16 (3.0×3.0x0.9mm) package. It is designed for a wide range of applications including industrial, consumer, and communication systems, delivering reliable performance and excellent value.

Key Specifications

Parameter 3-axis AMR magnetic sensor
Parameter +/-8G range
Parameter 16-bit resolution
Parameter I2C interface up to 400kHz
Parameter built-in SET/RESET
Parameter integrated temp sensor
Parameter 100uA operating current
Parameter 1uA standby
Parameter -40~85C
Parameter eCompass
Package LGA-16 (3.0×3.0x0.9mm)

Features

  • 3-axis magnetic field sensing with AMR technology
  • Wide full-scale range: +/-8 Gauss
  • 16-bit ADC for high precision measurement
  • Selectable ODR: 10Hz, 50Hz, 100Hz, 200Hz
  • Selectable oversampling: 512, 256, 128, 64
  • Built-in SET/RESET eliminates offset drift
  • On-chip temperature sensor for compensation
  • Low power: 100uA at 100Hz ODR
  • Ultra-low standby: 1uA
  • I2C digital interface up to 400kHz (Fast Mode)
  • Programmable interrupt pin (data ready)
  • Compact LGA-16 package: 3.0×3.0x0.9mm
  • Wide supply: 2.16V to 3.6V
  • Separate VDDIO for flexible interface voltage
  • RoHS compliant and lead-free
  • Pin/register compatible with HMC5883L

Applications

  • Electronic compass in smartphones and tablets
  • Wearable devices and smartwatches
  • Drone and UAV navigation
  • Gaming and VR motion tracking
  • Robot navigation and indoor positioning
  • Automotive compass and navigation
  • Metal detection and field measurement
  • Orientation detection in IoT devices
