STM32F100RBT6B

ARM Cortex-M3 32-bit MCU, 24MHz, 128KB Flash, 8KB SRAM, LQFP-64, 12-bit ADC, dual DAC, value line

12450

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

STM32F100RBT6B

Package：

LQFP-64

Brand：
Product Categories：

Quality Commitment

Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

STM32L053C8T6

STM32L052R8T6

STM32L010C6T6

STM32H7A3ZIT6

STM32H745ZIT6

STM32H743BIT6

STM32G030F6P6TR

STM32F767IIT6

Description

Product Overview

The STM32F100RBT6B is a low- and medium-density value line 32-bit microcontroller from STMicroelectronics, based on the ARM Cortex-M3 core. Operating at 24 MHz, it features 128 Kbytes of Flash memory and 8 Kbytes of SRAM in an LQFP-64 package. This device is part of the STM32F1 value line family, offering a cost-effective solution with a comprehensive set of peripherals including a 12-bit ADC, two 12-bit DACs, advanced PWM timer, and multiple communication interfaces for industrial and consumer applications.

Key Specifications

Core ARM Cortex-M3 32-bit
Maximum Frequency 24 MHz
Flash Memory 128 KB
SRAM 8 KB
Package LQFP-64 (10x10x1.4 mm)
Supply Voltage 2.0 V to 3.6 V
Operating Temperature -40C to +85C
ADC 1x 12-bit, up to 16 channels
DAC 2x 12-bit
DMA Channels 7
I/O Pins 51
Timers Up to 12
Communication Interfaces 2x I2C, 2x SPI, 3x USART, HDMI CEC

Features

  • ARM 32-bit Cortex-M3 CPU at 24 MHz, 1.25 DMIPS/MHz
  • Single-cycle multiplication and hardware division
  • 128 Kbytes Flash memory, 8 Kbytes SRAM
  • 2.0 to 3.6 V application supply and I/Os
  • POR, PDR and programmable voltage detector (PVD)
  • 4-to-24 MHz crystal oscillator with internal 8 MHz factory-trimmed RC
  • Low power modes: Sleep, Stop and Standby
  • VBAT supply for RTC and backup registers
  • Serial wire debug (SWD) and JTAG interfaces
  • 7-channel DMA controller
  • 1 x 12-bit, 1.2 us A/D converter (up to 16 channels) with temperature sensor
  • 2 x 12-bit D/A converters
  • 51 fast I/O ports, all mappable on 16 external interrupt vectors
  • 6-channel advanced-control PWM timer with dead time generation
  • Up to 12 timers total (general-purpose, watchdog, SysTick, basic)
  • CRC calculation unit, 96-bit unique ID
  • ECOPACK compliant, RoHS certified

Applications

  • Application control and user interfaces
  • Medical and hand-held equipment
  • PC and gaming peripherals
  • GPS platforms
  • Industrial applications and PLCs
  • Inverters and motor control
  • Printers and scanners
  • Alarm systems and video intercoms
  • HVAC systems
  • Consumer electronics

The STM32F100RBT6B is a value line 32-bit microcontroller from STMicroelectronics, based on the high-performance ARM Cortex-M3 RISC core operating at 24 MHz. Part of the STM32F1 series, this medium-density device features 128 Kbytes of embedded Flash memory and 8 Kbytes of SRAM, housed in an LQFP-64 package (10x10x1.4 mm). It offers an extensive range of enhanced peripherals and I/Os connected to two APB buses, including a 12-bit ADC with up to 16 channels, two 12-bit DACs, an advanced-control PWM timer with 6 channels, up to 12 timers in total, and up to 8 communication interfaces (I2C, SPI, USART, CEC). The STM32F100RBT6B operates from a 2.0 to 3.6 V power supply in the -40 to +85C temperature range, with a comprehensive set of power-saving modes for low-power application design. Its value line positioning makes it a cost-effective choice for industrial control, consumer electronics, and building automation applications.

The STM32F100RBT6B is built around the ARM Cortex-M3 32-bit RISC core, which provides 1.25 DMIPS/MHz performance with single-cycle multiplication and hardware division. The core executes Thumb-2 instructions for high code density. The system clock tree includes a 4-24 MHz HSE crystal oscillator, an 8 MHz factory-trimmed HSI RC oscillator, a 40 kHz LSI RC oscillator, and a 32 kHz LSE oscillator for RTC. A PLL generates the CPU clock up to 24 MHz. Power management includes Sleep (CPU stopped, peripherals active), Stop (all clocks stopped, SRAM retained), and Standby (minimum power, only RTC and backup registers active) modes. The nested vectored interrupt controller (NVIC) handles up to 43 maskable interrupt channels with 16 priority levels, enabling low-latency interrupt response. The 7-channel DMA controller supports memory-to-memory, peripheral-to-memory, and memory-to-peripheral transfers, reducing CPU overhead for data movement tasks.

Pin Name Type Function
PA0-PA15 I/O Port A I/O, 5V-tolerant, ADC channels 0-7
PB0-PB15 I/O Port B I/O, 5V-tolerant, ADC channels 8-9
PC0-PC15 I/O Port C I/O, 5V-tolerant, ADC channels 10-15
PD0-PD2 I/O Port D I/O (PD0/PD1 = OSC_IN/OSC_OUT)
VDD_1, VDD_2, VDD_3 Power Digital power supply (2.0V to 3.6V)
VSS_1, VSS_2, VSS_3 Ground Digital ground
VDDA Power Analog power supply
VSSA Ground Analog ground
VBAT Power Battery supply for RTC/backup
NRST I/O Reset pin (active low)
OSC_IN/PD0 Input High-speed external oscillator input
OSC_OUT/PD1 Output High-speed external oscillator output
OSC32_IN Input Low-speed external oscillator input (32kHz)
OSC32_OUT Output Low-speed external oscillator output (32kHz)
BOOT0 Input Boot mode selection
PA13/JTMS/SWDIO I/O JTAG TMS / SWD data I/O
PA14/JTCK/SWCLK I/O JTAG TCK / SWD clock
  • Industrial control systems and PLCs
  • Motor control and inverter drives
  • Consumer electronics and home appliances
  • Medical and handheld equipment
  • Building automation and HVAC
  • Security systems and alarm devices
  • Human-machine interface panels
  • Sensor data acquisition systems
Model Difference
STM32F100R8T6B 64KB Flash, same package and peripherals
STM32F100VBT6B LQFP-100 package, 80 I/O pins
STM32F101RBT6 Access line, 36MHz, 16KB SRAM, no DAC
STM32F103RBT6 Performance line, 72MHz, USB, CAN
STM32F051R8T6 Cortex-M0, 48MHz, lower cost entry option
