Description

Product Overview

The STM32F103TBU6 is a medium-density performance line 32-bit microcontroller from STMicroelectronics, built on the ARM Cortex-M3 core operating at 72 MHz. It features 128 Kbytes of Flash memory and 20 Kbytes of SRAM in a compact VFQFPN-36 package (6x6x1.0 mm). This high-performance device includes two 12-bit ADCs, advanced motor control PWM timer, USB 2.0 full-speed interface, CAN interface, and multiple communication interfaces, making it ideal for space-constrained applications requiring high performance and rich connectivity.

Key Specifications

Core ARM Cortex-M3 32-bit
Maximum Frequency 72 MHz
Flash Memory 128 KB
SRAM 20 KB
Package VFQFPN-36 (6x6x1.0 mm)
Supply Voltage 2.0 V to 3.6 V
Operating Temperature -40C to +85C
ADC 2x 12-bit, up to 10 channels
DMA Channels 7
I/O Pins 26
Timers 7 (3 GP + 1 advanced PWM + 2 WDG + SysTick)
Communication Interfaces 2x I2C, 2x SPI, 3x USART, USB, CAN

Features

  • ARM 32-bit Cortex-M3 CPU at 72 MHz, 1.25 DMIPS/MHz
  • Single-cycle multiplication and hardware division
  • 128 Kbytes Flash memory, 20 Kbytes SRAM
  • 2.0 to 3.6 V application supply and I/Os
  • POR, PDR and programmable voltage detector (PVD)
  • 4-to-16 MHz crystal oscillator with internal 8 MHz factory-trimmed RC
  • Low power modes: Sleep, Stop and Standby
  • VBAT supply for RTC and backup registers
  • Serial wire debug (SWD) and JTAG interfaces
  • 7-channel DMA controller
  • 2 x 12-bit, 1 us A/D converters (up to 16 channels) with dual sample-and-hold
  • 26 fast I/O ports, all mappable on 16 external interrupt vectors, 5V-tolerant
  • Advanced-control PWM timer with dead-time generation and emergency stop
  • Three general-purpose 16-bit timers with quadrature encoder input
  • USB 2.0 full-speed interface
  • CAN interface (2.0B Active)
  • CRC calculation unit, 96-bit unique ID
  • ECOPACK compliant, RoHS certified

Applications

  • Motor drives and industrial control
  • Medical and hand-held equipment
  • PC and gaming peripherals
  • GPS platforms and navigation
  • Industrial applications and PLCs
  • Inverters and power conversion
  • Printers and scanners
  • Alarm systems and video intercoms
  • HVAC systems
  • USB-connected devices

The STM32F103TBU6 is a medium-density performance line microcontroller from STMicroelectronics, featuring a high-performance ARM Cortex-M3 32-bit RISC core operating at 72 MHz. Part of the STM32F1 series, this device packs 128 Kbytes of Flash memory and 20 Kbytes of SRAM into a compact VFQFPN-36 package (6x6x1.0 mm), making it ideal for space-constrained embedded applications. Despite its small form factor, it offers a rich set of peripherals including two 12-bit ADCs with up to 10 channels and dual sample-and-hold capability, an advanced-control PWM timer for motor control with dead-time generation, three general-purpose 16-bit timers with quadrature encoder input, USB 2.0 full-speed interface, CAN 2.0B interface, and multiple serial communication interfaces (I2C, SPI, USART). The STM32F103TBU6 operates from a 2.0 to 3.6 V power supply in the -40 to +85C temperature range, with comprehensive power-saving modes for low-power designs.

The STM32F103TBU6 is built on the ARM Cortex-M3 32-bit RISC core, delivering 1.25 DMIPS/MHz at 72 MHz with single-cycle multiplication and hardware division support. The Thumb-2 instruction set provides excellent code density. The clock system features a 4-16 MHz HSE crystal oscillator, an 8 MHz factory-trimmed HSI RC oscillator, a 40 kHz LSI RC oscillator, and a 32 kHz LSE oscillator for the RTC. A PLL generates the maximum 72 MHz CPU clock. The nested vectored interrupt controller (NVIC) handles up to 43 maskable interrupt channels with 16 priority levels, enabling fast interrupt response critical for real-time applications. The 7-channel DMA controller supports autonomous data transfers between memory and peripherals, reducing CPU load. Power management includes three low-power modes: Sleep (CPU stopped), Stop (clocks stopped, SRAM retained), and Standby (minimum power). The dual ADC architecture with dual sample-and-hold enables simultaneous sampling of two analog signals, useful for motor control and power monitoring applications.

Pin Name Type Function
PA0-PA15 I/O Port A I/O, 5V-tolerant, ADC1/2_IN0-7
PB0-PB10 I/O Port B I/O, 5V-tolerant, ADC1/2_IN8-9
PB12-PB15 I/O Port B I/O, 5V-tolerant
VDD Power Digital power supply (2.0-3.6V)
VSS Ground Digital ground
VDDA Power Analog power supply
VSSA Ground Analog ground
VBAT Power Battery supply for RTC/backup
NRST I/O Active-low reset
OSC_IN/PD0 Input High-speed oscillator input
OSC_OUT/PD1 Output High-speed oscillator output
BOOT0 Input Boot mode selection
PA11/USB_DM I/O USB D- data line
PA12/USB_DP I/O USB D+ data line
PA13/SWDIO I/O SWD data I/O / JTAG TMS
PA14/SWCLK I/O SWD clock / JTAG TCK
PA15/JTDI I/O JTAG TDI
PB3/JTDO I/O JTAG TDO
PAD (EPP) Power Exposed pad, must connect to VSS
  • Motor control and drive systems
  • Industrial automation and PLCs
  • USB-connected peripherals and devices
  • CAN bus industrial networks
  • Medical and handheld equipment
  • Power conversion and inverters
  • Consumer electronics with USB connectivity
  • Compact sensor hubs and data loggers
Model Difference
STM32F103T8U6 64KB Flash, same package and peripherals
STM32F103RBT6 LQFP-64 package, 51 I/O pins
STM32F103CBT6 LQFP-48 package, 37 I/O pins
STM32F101TBU6 Access line, 36MHz, no USB/CAN, 16KB SRAM
STM32G431T6 Newer Cortex-M4F, 170MHz, math accelerator
