IRF7317TRPBF

20V dual P-channel MOSFET, -3.9A, 52mΩ RDS(on), logic level, SOIC-8 package

6520

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

IRF7317TRPBF

Package：

SOIC-8

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

IRLZ44NPBF

IRLR3110ZPBF

IRLML0100TRPBF

IRLML0030TRPBF

IRLR2905TRPBF

IRLH5034TRPBF

IRFS4310ZTRLPBF

IRFS4227TRLPBF

Description

Product Overview

The IRF7317TRPBF is a dual P-channel HEXFET power MOSFET from Infineon Technologies in a SOIC-8 package. Featuring 20V voltage rating and -3.9A per channel, this dual P-channel device is designed for high-side load switching and other low-voltage power management applications.

Key Specifications

Parameter Value
Drain-Source Voltage (VDSS) -20V
Continuous Drain Current (ID) -3.9A @ 25°C (per channel)
On-Resistance (RDS(on)) 52mΩ max @ VGS=-10V
On-Resistance @ -4.5V 70mΩ max
Gate Threshold Voltage (VGS(th)) -1V to -2.5V
Total Gate Charge (Qg) 11nC (typ) @ 4.5V
Power Dissipation 2W per channel
Operating Junction Temperature -55°C to +150°C
Package SOIC-8

Features

  • Dual P-channel MOSFET configuration
  • Logic level gate drive (-1 to -2.5V VGS(th))
  • Low on-resistance (52mΩ max)
  • Fast switching speed
  • Fully characterized avalanche energy
  • Compact SOIC-8 surface mount package
  • RoHS compliant and lead-free

Applications

  • High-side load switching
  • Battery management systems
  • DC-DC converters
  • Power management ICs
  • Portable electronics
  • Notebook power systems

The IRF7317TRPBF is a dual P-channel HEXFET power MOSFET housed in a SOIC-8 surface mount package. It features logic-level gate operation and low on-resistance, making it suitable for high-side load switching applications in low-voltage systems. The dual configuration saves valuable board space in compact power management designs.

The IRF7317TRPBF contains two independent P-channel enhancement-mode MOSFETs. Each device turns on when the gate-to-source voltage drops below the negative threshold voltage (-1V to -2.5V), forming a p-type inversion channel that allows hole current to flow from source to drain. In high-side switching applications, the source connects to the positive supply rail. Pulling the gate below the source voltage (negative VGS) turns the device on, connecting the load to the supply. The logic-level threshold allows direct drive from common 3.3V/5V logic systems with appropriate level shifting.

Pin Number Symbol Description
1 S1 Source – MOSFET 1
2 S2 Source – MOSFET 2
3 G1 Gate – MOSFET 1
4 D2 Drain – MOSFET 2
5 G2 Gate – MOSFET 2
6 D1 Drain – MOSFET 1
7 S2 Source – MOSFET 2
8 S1 Source – MOSFET 1
  • High-side load switching
  • Battery management systems
  • DC-DC converters
  • Power management ICs
  • Portable electronics
  • Notebook power systems
Model Manufacturer Voltage Package
IRF7319TRPBF Infineon 20V SOIC-8
SI4435 Vishay 20V SOIC-8
FDS4435 ON Semiconductor 20V SOIC-8
