IRF7862TRPBF

30V N-channel MOSFET, 21A, 3.3mΩ RDS(on), logic level, SOIC-8 package

9850

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

IRF7862TRPBF

Package：

SOIC-8

Brand：
Product Categories：
Quality Commitment
Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

IRLZ44NPBF

IRLR3110ZPBF

IRLML0100TRPBF

IRLML0030TRPBF

IRLR2905TRPBF

IRLH5034TRPBF

IRFS4310ZTRLPBF

IRFS4227TRLPBF

Description

Product Overview

The IRF7862TRPBF is a single N-channel HEXFET power MOSFET from Infineon Technologies in a SOIC-8 surface mount package. Rated at 30V with 21A continuous drain current, this device offers extremely low on-resistance and logic-level gate operation for high-efficiency power conversion.

Key Specifications

Parameter Value
Drain-Source Voltage (VDSS) 30V
Continuous Drain Current (ID) 21A @ Ta=25°C
On-Resistance (RDS(on)) 3.3mΩ max @ VGS=10V
On-Resistance @ 4.5V 4.5mΩ max
Gate Threshold Voltage (VGS(th)) 1.35V to 2.35V
Total Gate Charge (Qg) 30nC (typ) @ 4.5V
Gate-Drain Charge (Qgd) 9.8nC
Power Dissipation (PD) 2.5W @ Ta=25°C
Operating Junction Temperature -55°C to +150°C
Package SOIC-8

Features

  • Extremely low on-resistance (3.3mΩ max @ 10V)
  • Logic level gate drive (optimized for 5V)
  • Ultra-low gate impedance
  • Fully characterized avalanche voltage and current
  • 100% Rg tested
  • 20V VGS maximum gate rating
  • RoHS compliant and lead-free
  • Industry standard SOIC-8 package

Applications

  • Battery protection circuits
  • High-side and low-side load switch
  • Notebook processor power
  • Isolated DC-to-DC converters
  • Synchronous rectification
  • Power management systems

The IRF7862TRPBF is a 30V single N-channel HEXFET power MOSFET in a SOIC-8 package. It features very low static drain-to-source on-resistance at 4.5V gate-to-source voltage and is optimized for 5V gate drive voltage (logic level). The device is suitable for battery protection, high-side and low-side load switching, notebook processor power, and isolated DC-to-DC converters.

The IRF7862TRPBF is an N-channel enhancement-mode power MOSFET. When the gate-source voltage exceeds the threshold (1.35-2.35V), an n-type inversion channel forms, enabling current flow from drain to source. The extremely low on-resistance of 3.3mΩ minimizes conduction losses, contributing to high system efficiency. The logic-level gate threshold allows direct interface with 3.3V and 5V microcontroller outputs without additional level-shifting circuitry. The device is designed for switching operation between cut-off and ohmic regions.

Pin Number Symbol Description
1-4 Drain (D) Drain terminals (multi-pin for high current handling)
5 Gate (G) Gate control terminal
6-8 Source (S) Source terminals (multi-pin for high current handling)
  • Battery protection circuits
  • High-side and low-side load switch
  • Notebook processor power
  • Isolated DC-to-DC converters
  • Synchronous rectification
  • Power management systems
Model Manufacturer Voltage Package
IRF7832TRPBF Infineon 30V SOIC-8
BSC030N03LS Infineon 30V TSDSON-8
SI7820 Vishay 30V SOIC-8
