STM8S003F3U6TR

Value-line 8-bit STM8S MCU, 16MHz, 8KB Flash, 1KB RAM, 128B EEPROM, 10-bit ADC, UFQFPN20 TR

15000

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

STM8S003F3U6TR

Package：

UFQFPN-20 (3x3x0.6 mm), Tape & Reel

Brand：
Product Categories：

Quality Commitment

Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

TMS320F28062PZT

TMS320DM368ZCE

TMS320C6657CZHA

STR710FZ2T6

STM8S207C8T6

STM8S105K4T6C

STM8S105C6T6C

STM8L101F3U6

Description

Product Overview

The STM8S003F3U6TR is a value-line 8-bit microcontroller designed for cost-sensitive high-volume applications. Part of STMicroelectronics’ STM8S family, it features the advanced STM8 core with Harvard architecture operating at 16 MHz, 8 KB of Flash program memory, 1 KB of RAM, and 128 bytes of true data EEPROM supporting up to 100,000 write/erase cycles. The UFQFPN20 tape-and-reel package is optimized for automated high-volume assembly. With a wide 2.95V to 5.5V operating range, robust I/O design immune to current injection, and integrated clock oscillators and watchdog, it significantly reduces system cost and board space.

Key Specifications

Core STM8S 8-bit, Harvard architecture
Maximum Frequency 16 MHz
Flash Memory 8 KB
RAM 1 KB
EEPROM 128 bytes (true data EEPROM)
Supply Voltage 2.95 V to 5.5 V
Operating Temperature -40°C to +85°C
GPIO Count 16 (high-sink capable)
ADC 10-bit, 5 channels, scan mode
Package UFQFPN-20 (Tape & Reel)

Features

  • 16 MHz STM8 core with 3-stage pipeline and Harvard architecture
  • 8 KB Flash + 128 byte EEPROM (100k endurance)
  • Wide 2.95V to 5.5V operating voltage
  • Advanced control timer: 16-bit, 4 CAPCOM, 3 complementary outputs
  • 16-bit general purpose timer (3 CAPCOM channels)
  • 8-bit basic timer with 8-bit prescaler
  • Window and independent watchdog timers
  • 10-bit ADC with 5 channels and analog watchdog
  • UART with SmartCard, IrDA, LIN master mode
  • SPI up to 8 Mbit/s, I2C up to 400 Kbit/s
  • Robust I/O design immune to current injection
  • SWIM debug interface for fast programming

Applications

  • Consumer appliances and small electronics
  • Motor control and LED lighting
  • LIN bus automotive sub-nodes
  • Power supply and battery chargers
  • Industrial sensor interfaces
  • Remote controls and user interfaces
  • Toys and educational electronics

The STM8S003F3U6TR is a value-line 8-bit microcontroller from STMicroelectronics’ STM8S family, offering 8 Kbytes of Flash program memory with integrated true data EEPROM (128 bytes). Based on the advanced STM8 core with Harvard architecture and 3-stage pipeline operating at 16 MHz, it delivers cost-effective performance for high-volume applications. Features include a 10-bit ADC with up to 5 channels, advanced control timer with 4 CAPCOM channels and 3 complementary outputs, general purpose timer, basic timer, and communication interfaces including UART (SmartCard/IrDA/LIN), SPI (8 Mbit/s), and I2C (400 Kbit/s). The wide 2.95V to 5.5V operating range and robust I/O design make it suitable for cost-sensitive industrial and consumer applications.

The STM8S003F3U6TR uses the STM8 8-bit core with Harvard architecture and 3-stage pipeline, executing up to 16 MIPS at 16 MHz. The core features extended instruction set including 8×8 multiplication and 16/8-bit division operations. Clock management supports four master clock sources: low-power crystal resonator, external clock input, internal user-trimmable 16 MHz RC, and internal low-power 128 kHz RC, with clock security system for fail-safe operation. Power management includes three low-power modes: Wait, Active-halt, and Halt, with individual peripheral clock gating for optimized power consumption. Two independent watchdog timers (window and independent) and brown-out reset ensure system robustness. The nested interrupt controller handles 32 interrupts with up to 27 external interrupt sources across 6 vectors.

Pin Name Type Description
PA1/OSCIN I/O Port A1 / Oscillator input
PA2/OSCOUT I/O Port A2 / Oscillator output
PA3 I/O Port A3 / TIM2_CH3
PB0 I/O Port B0 / ADC_ETR / TIM1_CH2N
PB1 I/O Port B1 / ADC_AIN1 / TIM1_CH3N
PB2 I/O Port B2 / ADC_AIN2 / TIM1_CH1
PB3 I/O Port B3 / ADC_AIN3 / TIM1_CH2
PB4 I/O Port B4 / ADC_AIN4 / TIM1_CH3
PB5 I/O Port B5 / SPI_MOSI / I2C_SDA
PC1 I/O Port C1 / TIM1_CH1 / UART2_CK
PC2 I/O Port C2 / TIM1_CH2
PC3 I/O Port C3 / TIM1_CH3
PC4 I/O Port C4 / SPI_CLK / TIM1_CH4
PC5 I/O Port C5 / SPI_MISO
PC6 I/O HS / Port C6 / SPI_MOSI
PC7 I/O HS / Port C7 / SPI_MISO
PD5 I/O HS / Port D5 / UART2_TX
PD6 I/O HS / Port D6 / UART2_RX
NRST I Active-low reset
VDD/VSS P Power supply / Ground
  • Consumer electronics and small appliances
  • Motor control and lighting systems
  • Industrial sensor interfaces
  • Automotive body electronics (LIN bus)
  • Smart home devices and remote controls
  • Battery chargers and power supplies
  • Toys and gaming accessories
Model Flash Package Description
STM8S003F3P6 8KB TSSOP20 Same device, tray packing
STM8S003K3T6C 8KB LQFP32 More I/O pins (28)
STM8S103F3P6 8KB TSSOP20 Access line, more features
STM8S005C6T6 32KB LQFP48 Higher density value line
STM8L101F3U6 8KB UFQFPN20 Ultra-low-power variant
