Product Overview
The TC4427AVOA713 is a dual 1.5 A high-speed MOSFET gate driver from Microchip Technology, featuring two independent non-inverting driver channels in a compact SOIC-8 surface-mount package. As an improved version of the classic TC4427 family, the TC4427A series adds matched leading- and falling-edge propagation delays, enabling accurate handling of very short pulses down to the 25 ns range. Operating from a 4.5 V to 18 V supply, these drivers deliver 1.5 A peak source and sink current, capable of switching 1000 pF of capacitive load in under 30 ns. The devices provide exceptional robustness against latch-up, withstanding >500 mA reverse current on outputs, -5 V negative input swings, and ground pin noise spikes of up to 5 V. With low output impedance (7 Ω typical) and 4 kV ESD protection, the TC4427AVOA713 is a versatile solution for driving power MOSFETs and IGBTs in switching power supplies, motor controls, and Class-D audio applications.
Key Specifications
| Driver Type | Dual MOSFET/IGBT Gate Driver |
| Configuration | 2 channels, non-inverting (low-side) |
| Peak Output Current | 1.5 A (source and sink) |
| Supply Voltage Range | 4.5 V to 18 V |
| Rise Time (tr) | 25 ns typ. @ 1000 pF load |
| Fall Time (tf) | 25 ns typ. @ 1000 pF load |
| Propagation Delay (tD1/tD2) | 30 ns typ. (matched) |
| Output Impedance | 7 Ω typ. |
| Input Logic Threshold | VIH = 2.4 V min, VIL = 0.8 V max |
| Supply Current (Logic 1) | 1 mA typ. |
| Supply Current (Logic 0) | 100 µA typ. |
| Latch-up Protection | > 500 mA reverse current withstand |
| Negative Input Tolerance | Down to -5 V |
| ESD Protection | 4 kV HBM |
| Operating Temperature | -40°C to +85°C |
| Package | SOIC-8 (surface mount) |
Features
- Dual 1.5 A high-speed MOSFET gate drivers
- Non-inverting configuration (both channels)
- 4.5 V to 18 V wide operating range
- High capacitive load drive: 1000 pF in 25 ns
- Matched rise, fall, and propagation delay times
- Short propagation delay: 30 ns typical
- Low output impedance: 7 Ω typical
- Superior latch-up protection (>500 mA reverse current)
- Tolerates -5 V negative inputs
- 4 kV ESD protection (HBM)
- Low quiescent supply current
- Pin-compatible with TC427/TC4427 family
- SOIC-8 surface mount package
- RoHS compliant, lead-free
- Industrial temperature range: -40°C to +85°C
Applications
- Switch-mode power supplies (SMPS)
- DC-DC converters and switching regulators
- Motor drive and control circuits
- Class-D audio power amplifiers
- Power MOSFET and IGBT gate drivers
- Line drivers and pulse transformer drivers
- Synchronous rectification drivers
- Battery management and charging systems
- Solar inverters and renewable energy
- Industrial automation and power control
- LED lighting drivers
- Telecom and datacom power systems
