Product Overview
The TLV3491AIDBVR is a single-channel nanopower push-pull output voltage comparator from Texas Instruments, optimized for ultra-low-power voltage monitoring and threshold detection in battery-powered systems. Operating from a 1.8 V to 5.5 V single supply and consuming only 0.85 uA typical quiescent current, it achieves 6 us propagation delay, an excellent speed-to-power ratio. The rail-to-rail input common-mode range extends 200 mV beyond both supply rails, and the push-pull CMOS output stage eliminates the need for an external pull-up resistor, reducing component count and power consumption. With a maximum offset voltage of 15 mV, 10 pA typical input bias current, and built-in hysteresis for noise immunity, the TLV3491 provides reliable performance across the -40 degC to +125 degC industrial temperature range. Packaged in a tiny 5-pin SOT-23 (DBV) package with a footprint of just 8.12 mm2, it is ideal for space-constrained portable and battery-operated devices. The TLV3491 family also includes dual (TLV3492) and quad (TLV3494) versions in various package options, making it suitable for power-sensitive low-voltage applications including battery monitoring, undervoltage detection, zero-crossing detection, power-on reset, window comparators, and wake-up event detection.
Key Specifications
| Number of Channels | 1 |
| Output Type | Push-Pull (CMOS) |
| Supply Voltage Range | 1.8 V to 5.5 V |
| Supply Current (Iq) | 0.85 uA typical, 1.2 uA max |
| Propagation Delay | 6 us typical |
| Input Offset Voltage (Vos) | 15 mV max @ 25 degC |
| Input Bias Current | 10 pA typical, 100 pA max |
| Input Common-Mode Range | 0.2 V below V- to 0.2 V above V+ (rail-to-rail + 200mV) |
| Hysteresis | Yes (built-in) |
| Output Sink/Source Current | Push-pull CMOS output |
| Operating Temperature | -40 degC to +125 degC |
| ESD Protection | 2 kV HBM |
| Package | SOT-23-5 (DBV) |
| Footprint Area | 8.12 mm2 (2.9 x 2.8 mm) |
Features
- Very low supply current: 0.85 uA typical
- Push-pull CMOS output stage (no pull-up resistor needed)
- Rail-to-rail input common-mode range
- Input range extends 200 mV beyond supply rails
- Fast response: 6 us propagation delay
- Supply voltage: 1.8 V to 5.5 V single supply
- Built-in hysteresis for noise immunity
- Low input offset voltage: 15 mV max
- Very low input bias current: 10 pA
- Compact SOT-23-5 surface mount package
- Wide temperature range: -40 degC to +125 degC
- RoHS compliant
Applications
- Battery-powered and portable electronics
- Power supply voltage monitoring and supervision
- Under-voltage and over-voltage detection
- Zero-crossing detection circuits
- Window comparators and level detectors
- Power-on reset (POR) and brown-out detection
- Relaxation oscillators
- Wake-up and sleep event detection
- Headphone jack detection in portable audio
- Low-voltage two-cell battery systems
- Energy harvesting applications
- Wireless sensor networks
