ADUM121N1BRZ

Dual-channel digital isolator, 3kV rms, 1/1 direction, 150Mbps, 13ns delay, 100kV/us CMTI, 1.7-5.5V, fail-safe high, 8-SOIC, ADI iCoupler ADUM121N.

15000

Effective Inventory
Go to Inquiry

Image for reference only

Manufacturer Part：

ADUM121N1BRZ

Package：

8-Lead SOIC

Brand：
Product Categories：

Quality Commitment

Shipping & Payment
Service & Packaging
Product Manual
Other recommendations you may be interested in.

AFE4490RHAT

ADV7471BBCZ

ADUM1411ARWZ

ADS1299IPAGR

ADS1256IDBR

ADS1246IPWR

ADS1115IRUGR

ADG719BRMZ

Description

Product Overview

The ADUM121N1BRZ is a dual-channel digital isolator from Analog Devices featuring i Coupler technology, with one channel in each direction (1/1 channel configuration) and fail-safe high output. The device provides 3.0 kV rms withstand voltage per UL 1577 and supports data rates up to 150 Mbps with propagation delay as low as 13 ns maximum at 5V operation. Based on ADI monolithic air core transformer technology, the ADuM121N delivers superior performance compared to optocoupler alternatives, including lower power consumption, tighter channel matching (3 ns maximum), and excellent common-mode transient immunity (CMTI) of 75 kV/microsecond minimum (100 kV/microsecond typical). The device operates with supply voltages from 1.8V to 5.5V on either side of the isolation barrier, enabling voltage level translation between different voltage domains. The ADUM121N1BRZ is pin-compatible with the ADuM1281 and ADuM1201, and is AEC-Q100 qualified for automotive applications.

Key Specifications

Parameter Conditions Min Typ Max Unit
Isolation Channels 1/1 direction 2 (one each direction)
Isolation Voltage UL 1577, 1 min 3000 V rms
Max Working Voltage (VORM) VDE, peak 565 V peak
Data Rate 5V operation 150 Mbps
Propagation Delay (5V) tPHL/tPLH 7.5 13 ns
Propagation Delay (1.8V) tPHL/tPLH 8.7 15 ns
Pulse Width Distortion 5V 0.5 3 ns
Channel Matching Same direction 0.7 3.0 ns
CMTI (Min) 75 100 kV/us
Supply Voltage Both sides 1.7 5.5 V
Supply Current Side 1 1Mbps, 5V 4.7 8.0 mA
Supply Current Side 2 1Mbps, 5V 4.9 7.7 mA
Rise/Fall Time CL=15pF 2.5 ns
Fail-Safe Output N1 variant High
Package 8-Lead SOIC (narrow body)
Operating Temperature -40 +125 C
Safety Approvals UL 1577, IEC 62368-1, VDE 0884-17, CQC

Features

  • 3.0 kV rms dual-channel digital isolator (1/1 direction)
  • i Coupler magnetic isolation technology
  • Up to 150 Mbps data rate
  • Low propagation delay: 13 ns max (5V)
  • Tight channel matching: 3.0 ns max
  • High CMTI: 75 kV/us min, 100 kV/us typ
  • Wide supply: 1.7V to 5.5V on both sides
  • 1.8V to 5V level translation
  • Fail-safe high output (N1 variant)
  • Patented refresh ensures DC correctness
  • AEC-Q100 qualified (automotive)
  • Pin-compatible with ADuM1281/ADuM1201
  • 8-lead SOIC, RoHS compliant
  • -40C to +125C industrial temperature range

Applications

  • General-purpose multi-channel signal isolation
  • SPI, I2C, and digital interface isolation
  • RS-232, RS-485, CAN bus isolation
  • Industrial automation and process control
  • Motor drive and power inverter isolation
  • Data acquisition system isolation
  • Medical equipment patient isolation
  • High voltage sensing and measurement
  • Automotive electronics (AEC-Q100)
  • Power supply feedback isolation

The ADUM121N1BRZ is a high-performance dual-channel digital isolator from Analog Devices built on i Coupler magnetic isolation technology, with one channel in each direction (1/1 configuration) and fail-safe high output. Unlike optocouplers relying on LEDs and photodiodes, i Coupler technology uses chip-scale air-core transformers monolithically integrated with CMOS circuitry, delivering significantly better speed, power efficiency, timing precision, and long-term stability. The device supports 150 Mbps data rates with only 13 ns maximum propagation delay at 5V, tight 3 ns channel-to-channel matching, and 75 kV/us minimum common-mode transient immunity for reliable operation in noisy environments. Both sides operate from 1.7V to 5.5V supplies, enabling voltage level translation. The patented refresh architecture guarantees DC correctness without requiring signal toggling. AEC-Q100 qualified for automotive use. Pin-compatible with industry-standard ADuM1281/ADuM1201.

The ADUM121N1BRZ uses Analog Devices i Coupler magnetic isolation technology. Each channel contains a monolithic air-core transformer integrated with CMOS transmitter and receiver circuits. Input logic transitions are encoded into high-frequency pulses that couple magnetically across the isolation barrier through the transformer. The receiver detects these pulses and reconstructs the output waveform. A patented refresh mechanism periodically sends confirmation pulses to maintain DC correctness even when the input is static. The fail-safe high (N1) feature sets the output to logic high if the input side loses power. Wide dual supply range (1.7V to 5.5V each side) enables automatic level translation between different voltage domains.

Pin No. Name Side Description
1 VDD1 Side 1 Side 1 power supply (1.7V to 5.5V). Bypass with 0.1uF to GND1.
2 VIA Side 1 Channel A input (Side 1 to Side 2 direction).
3 VIB Side 2 Channel B input (Side 2 to Side 1 direction).
4 GND1 Side 1 Side 1 ground.
5 GND2 Side 2 Side 2 ground.
6 VOA Side 2 Channel A output (Side 1 to Side 2 direction).
7 VOB Side 1 Channel B output (Side 2 to Side 1 direction).
8 VDD2 Side 2 Side 2 power supply (1.7V to 5.5V). Bypass with 0.1uF to GND2.

Note: ADuM121N = 1/1 channel config. N1 = fail-safe high output.

  • SPI, I2C, and serial digital interface isolation
  • RS-485/RS-232/CAN bus transceiver isolation
  • Industrial PLC and distributed I/O signal isolation
  • Motor drives, inverters, and power electronics
  • Medical equipment patient safety isolation
  • High voltage measurement and sensing circuits
  • Data acquisition system channel isolation
  • Automotive electronics (AEC-Q100 qualified)
  • Power supply monitoring and feedback isolation
  • Test and measurement equipment front-end isolation
Model Manufacturer Key Difference
ADUM120N1BRZ Analog Devices 2/0 channels (both same direction), same speed
ADUM121N0BRZ Analog Devices 1/1 channels, fail-safe LOW (N0 variant)
