SSC-YG101-IC1

Product Overview SSC-YG101-IC1 is a power management IC for LED backlight driving, integrated boost converter with multi-string current control. Key Specifications Function LED backlight driver IC Topology Boost converter with multi-string Input Voltage 5V to 28V LED Strings Multi-string current control Dimming PWM dimming Package QFN Features Integrated boost converter for LED backlight Multi-string current […]

SI4539ADY-T1-E3

Product Overview SI4539ADY-T1-E3 is a dual N/P-channel enhancement mode MOSFET with 30V/−30V VDS, 3.9A/−3.2A ID, SOIC-8 package. Key Specifications Type Dual N/P-channel MOSFET VDS(N) 30 V VDS(P) −30 V ID(N) 3.9 A ID(P) −3.2 A RDS(on)(N) 35 mΩ RDS(on)(P) 65 mΩ Package SOIC-8 Features Dual complementary N/P-channel in one package Low RDS(on) 35mΩ/65mΩ 30V drain-source […]

ISL80101IRAJZ

Product Overview ISL80101IRAJZ is a 1A low-dropout regulator with 1.8V to 5.5V input, adjustable output, 250mV dropout at 1A, QFN-12 package. Key Specifications Output Current 1 A Output Voltage 0.8V to 5V adjustable Dropout Voltage 250 mV at 1A Input Voltage 1.8V to 5.5V PSRR 70 dB at 1kHz Quiescent Current 65 µA Package QFN-12 […]

AS179-92LF

Product Overview AS179-92LF is a high-linearity SP3T RF switch with 0.1dB to 3GHz insertion loss, QFN-16 package for wireless applications. Key Specifications Configuration SP3T Frequency Range DC to 3 GHz Insertion Loss 0.1 dB at 900 MHz Isolation 35 dB at 900 MHz P1dB 33 dBm Supply Voltage 2.7V to 5.5V Package QFN-16 Features High […]

LM78S40N/NOPB

Product Overview LM78S40N is a switching voltage regulator subsystem with 1.25A switch, 40V breakdown, DIP-16 package for step-up/step-down/inverting. Key Specifications Function Switching regulator subsystem Switch Current 1.25 A Switch Breakdown 40 V Switching Frequency Up to 100 kHz Reference Voltage 1.25V Package DIP-16 Topologies Step-up, step-down, inverting Features Versatile switching regulator building block 1.25A internal […]

SN74ACT373DBR

Product Overview SN74ACT373DBR is an octal transparent D-type latch with 3-state outputs, SSOP-20 package. Key Specifications Function Octal transparent D-type latch Supply Voltage 4.5V to 5.5V Propagation Delay 7 ns Output Current ±24 mA Package SSOP-20 Features 3-state outputs, output enable Features 8-bit transparent latch 3-state outputs for bus interface 7ns fast propagation delay ±24mA […]

SN74AHCT273DBR

Product Overview SN74AHCT273DBR is an octal D-type edge-triggered flip-flop with clear, SSOP-20 package. Key Specifications Function Octal D-type flip-flop with clear Supply Voltage 4.5V to 5.5V Propagation Delay 10 ns Trigger Edge-triggered (rising edge) Package SSOP-20 Features Active-low clear Features 8-bit edge-triggered D flip-flop Active-low clear input 10ns propagation delay SSOP-20 compact package AHCT logic […]

SN74AHCT245DBR

Product Overview SN74AHCT245DBR is an octal bus transceiver with 3-state outputs, direction control, SSOP-20 package. Key Specifications Function Octal bus transceiver Supply Voltage 4.5V to 5.5V Propagation Delay 8 ns Output Current ±24 mA Package SSOP-20 Features 3-state outputs, direction control Features Octal bidirectional bus transceiver 3-state outputs for bus sharing Direction control pin ±24mA […]

TPS76330DBVR

Product Overview TPS76330DBVR is a 150mA ultra-low-dropout regulator with 3.0V fixed output, 150mV dropout at 150mA, SOT-23-5 package. Key Specifications Output Current 150 mA Output Voltage 3.0V fixed Dropout Voltage 150 mV at 150mA Quiescent Current 85 µA Input Voltage 3.15V to 10V PSRR 65 dB at 1kHz Package SOT-23-5 Features 3.0V fixed output Ultra-low […]

LNK6779K-TL

Product Overview LNK6779K-TL is a 20W off-line switcher with primary-side regulation, no optocoupler needed, DIP-8 package for isolated power supplies. Key Specifications Topology Off-line switcher with PSR Power Up to 20W Input Voltage 85VAC to 265VAC Switching Frequency 66 kHz Regulation Primary-side (no optocoupler) Package DIP-8 Features EcoSmart, auto-restart Features Primary-side regulation eliminates optocoupler Universal […]
