74HC05D,118

Product Overview The 74HC05D,118 from Nexperia is a hex inverter with open-drain outputs in a 14-pin SOIC package. The open-drain outputs enable wired-OR logic, level translation, and bus driving with external pull-up resistors to any voltage up to 6V. Key Specifications Function Hex inverter (open-drain) Supply Voltage 2.0V to 6.0V Propagation Delay 12 ns at […]

74HC1G02GW,125

Product Overview The 74HC1G02GW,125 from Nexperia is a single 2-input NOR gate in an ultra-compact SOT-353 package. The 2.0V to 6.0V supply range supports a wide range of logic voltage domains in space-constrained designs. Key Specifications Function Single 2-input NOR gate Supply Voltage 2.0V to 6.0V Propagation Delay 7 ns at 5V Output Drive ±5.2 […]

TPS73101DBVR

Product Overview The TPS73101DBVR from TI is an adjustable 150 mA very low noise LDO regulator with only 30 µVRMS output noise and 75 mV dropout at full load. The 72 dB PSRR makes it ideal for noise-sensitive RF and analog power rails such as VCOs, PLLs, and LNAs. Key Specifications Function Adjustable, 150mA very […]

STM8L052C6T6

Product Overview The STM8L052C6T6 from STMicroelectronics is an ultra-low-power STM8 microcontroller running at 16 MHz with 32 KB Flash and 2 KB SRAM. It integrates USART, SPI, I2C, 12-bit ADC, DAC, comparators, and RTC in a 48-pin LQFP package for battery-powered and energy-harvesting applications. Key Specifications Core STM8 16-bit Max Clock 16 MHz Flash 32 […]

5M160ZE64C5N

Product Overview The 5M160ZE64C5N from Intel (Altera) is a MAX V CPLD with 160 macrocells and 41 I/O pins in a 64-pin EQFP package. It features on-chip flash configuration storage, an internal oscillator, and 1.8V core with 3.3V I/O for glue logic and bus interfacing. Key Specifications Function MAX V CPLD, 160 macrocells Macrocells 160 […]

UCC21710DWR

Product Overview The UCC21710DWR from TI is a reinforced isolated single IGBT/SiC MOSFET gate driver providing 3 kV RMS isolation, ±10 A peak drive, integrated DESAT fault detection, and active Miller clamp. It targets high-power inverters in EV, solar, and motor drive applications. Key Specifications Function Isolated single IGBT/SiC gate driver Isolation 3 kV RMS […]

NCT6776D

Product Overview The NCT6776D from Nuvoton is a Super I/O controller with comprehensive hardware monitoring including 10 voltage inputs, 6 fan channels with PWM/DC control, thermistor/PECI/SMBus temperature sensing, keyboard controller, and UART/LPT interfaces via LPC bus. Key Specifications Function Super I/O with hardware monitor Features HWM, FAN control, GPIO, WDT, KBC, LPT, UART Voltage Inputs […]

NCP5501DT33RKG

Product Overview The NCP5501DT33RKG from onsemi is a 3.3V fixed 1A LDO regulator with ultra-low 40 µA quiescent current. The wide 18V input range and DPAK-4 package suit automotive and industrial always-on power rails where efficiency at light load is critical. Key Specifications Function 3.3V, 1A very low Iq LDO Output Voltage 3.3V fixed Output […]

NHI350AM4,SLJ3Z

Product Overview The NHI350AM4,SLJ3Z from onsemi is a 5V fixed 3A positive voltage regulator in a thermally-efficient D2PAK-3 surface-mount package. It provides robust 5V regulation from up to 26V input with internal current limit and thermal shutdown. Key Specifications Function 5V fixed, 3A positive voltage regulator Output Voltage 5.0V Output Current 3A Dropout Voltage 2V […]

M74VHC1GT125DT1G

Product Overview The M74VHC1GT125DT1G from onsemi is a single bus buffer/line driver with 3-state output in an ultra-compact SOT-353 package. 5V-tolerant inputs allow level translation from 5V to 3.3V domains. The active-low output enable provides tri-state for bus sharing. Key Specifications Function Single bus buffer with 3-state output Supply Voltage 2.0V to 5.5V Propagation Delay […]
